Filter Cartridge Dust Collector (AR-CH4-80)

Get Latest Price

Incoterm:: FOB

Min. Order:: 1 Set/Sets

Min. Order:: 1 Set/Sets

Delivery Time:: 30 Days

Transportation:: Ocean

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	3000
Supply Ability:	3000
Incoterm:	FOB
Certificate:	SGS, ISO9001
Transportation:	Ocean

Product Description

Donaldson Dust Collector(dust bag, dust collecting machine)Dust collector system
Construction: Mild Steel Sheet / Stainless steel
Filtration dust type: Various dusts collection
Filter media type: Different dust type for different applications.
Filter Area (Sq. M. ): Different filter area for different filter media type
Pulse valve controller: Available, Timer board or Delta pressure controller
Differential pressure gauge: Available, Megnehelic, USA brand
Abrasive inlet duct: Available
Air inlet duct: Available
Air outlet duct: Available
Compressed air tank: Available
Hoppers: Available
Slide gate: Available
Dust drum: Available, 200 L
Supporting legs: Available
Leg bracings: Available
Compressed air piping: Available
Compressed air pressure gauge: Available
Compressed air filter: Available
Painting color: Customerized
Note: Similar to Donaldson dust collector!

Modal	Air Flow	Filter Area	No.of Cartridges	Operation Resistance	Filtration Efficiency	Height	Width	Depth	Gross Weight
Modal	m3/h	m2	pc	Pa	%	mm	mm	mm	Kg
AR 2-8	3300-7500	184	8	Initial Resistance 120-250 Normal operation resistance 500-700 Final Resistance 1000-1250	99.99	3175	1016	2159	841
AR4-16	6600-15000	368	16			4115	1016	2159	1164
AR3-24	10000-22000	552	24			3632	2032	2159	1695
AR4-32	13500-30000	736	32			4115	2032	2159	2032
AR3-36	15000-33500	828	36			3632	3048	2159	2377
AR3-48	20000-45000	1104	48			3632	4064	2159	3136
AR4-48	20000-45000	1104	48			4115	3048	2159	2859
AR464	20000-45000	1472	64			4115	4064	2159	3700
