JCJX-FZ17/A turning type alloy-wire drawing machine
Your message must be between 20 to 2000 characters
Contact NowUsage:This type is used for drawing Nickel Alloy wire or Copper Alloy wire from 1.5mm to 0.4mm-0.8mm
Main Spec:
|
Machine type |
JCJX-FZ17/A |
|
Control system |
Dual inverter+PLC+HMI |
|
Drawing dies No./Max. |
17 |
|
Max. Inlet diameter |
Ø 1.50mm |
|
Outlet diameter |
Ø 0.40--0.80mm |
|
Max. Drawing line speed |
240m/min |
|
Capstan |
Tool steel |
|
Main motor |
5.5KW |
|
Spooler motor |
1.1KW |
|
Spool bobbin size |
DIN160/200/250 or according to customers requirements |
|
Traversing unit |
Stepping motor |
|
Transmission type |
Teeth belt + Flat belt |
|
Max .loading capacity |
50KG |
|
Lubrication type |
Full immersed |
|
Power source |
380V 50/60HZ or others |
|
Machine dimension (mm) |
2000×1600×1900 |
|
Machine weight |
2500KG |
