copper wire extrusion machine
- Payment Type:
- T/T, L/C, D/A, D/P
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Transportation:
- Ocean
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | CHINA |
|---|---|
| Payment Type: | T/T,L/C,D/A,D/P |
| Certificate: | CE ISO |
| Transportation: | Ocean |
extruding machine,extruding m/c
Usage:
1).Apply for wire &cable monolayer ,double-decked and triple extrusive for PVC,LDPE,XLPE,LSHF,NYLON,TPU and so on.
70 extruder production line parameter:
|
Machine model |
JCJX-70 |
|
Screw diameter |
Ø70 |
|
L/D ratio |
25:1 |
|
Rotation speed(m/min) |
15-110 |
|
PVC extrusion capacity(kg/h) |
130 |
|
LDPE extrusion capacity(kg/h) |
86 |
|
PP extrusion capacity(kg/h) |
68 |
|
Main-machine power(KW) |
22 |
|
Finished wire dia.(mm) |
2.0-12.0 |
|
Line speed(m/min) |
10-350 |
|
Pay-off style |
Double axis |
|
Pay-off bobbin(mm) |
500-630 |
|
Haul-off unit |
Capstan type |
|
Accumulate length(m) |
220 |
|
Take-up bobbin dia. |
630-800mm |
|
Electrical control |
PLC |
