3 Phase Panasonic Electrical Parts Stable Quality Metal Can Body Welding Machine

Product Description Automatic seam welding machine

Product Type:	FBZ-A	/FBZ-B	FBZ-C
Power	3N380V/50HZ---35KVA
Welding speed:	6-18m/min	6-18m/min	6-24m/min
Capacity:	≤40cans/min	≤60cans/min	≤200cans/min
Diameter:	250-290mm	120-180mm	52-180mm
Height:	200-420mm	≤250mm	≤315mm
Overlap:	0.8-1.0mm	0.6-0.9mm	0.16-0.3m
Thickness:	0.28-0.4mm	0.18-0.4mm	0.16-0.3mm
Copper wire	Ø1.5 mm
Net Weight:	1850kg
Dimension:	2000x1800x1600mm

Semi automatic forward seam welding machine

Model:	FN2000-A	FN2000-B	FN2000-C	FN2000-D
Power:	3N380V/50HZ----18KVA			3N380V/50HZ-46KVA
Welding speed:	5-10m/min			2-6m/min
Capacity:	10-20cans/min			10-20cpm
Diameter:	Ø105-300mm	52-176mm	105-300mm	72-500mm
Height:	≤400mm	≤250mm	≤400mm	≤1000mm
Overlap:	3-4mm	2-3mm	3-4mm	6-8mm
Thickness:	0.18-0.4mm	0.18-.04mm	0.18-.05mm	0.3-0.8mm
Welding material	Tin	Tin	Tin/Galvanized	Tin/Galvanized/cold roller sheet
Copper wire:	Ø1.5 mm T2			1.8-2.0mm T2
Net Weight:	1000kgs			1200kg
Dimension:	2200x1100x1600mm			2500x1100x1600mm

Semi automatic backward seam welding machine

Model:	FB2000-A	FB2000-B
Power:	3N380V/50HZ----18KVA
Welding speed:	≤6-18m/min
Capacity:	20-50cans/min
Diameter:	65-290mm	52-180mm
Height:	70-400mm
Overlap:	0.6-1.2mm	0.4-0.9mm
Thickness:	0.18-0.4mm	0.18-0.35mm
Copper wire:	Ø1.5 mm T2
Net Weight:	1300kgs
Dimension:	1350x1300x1700mm

Related Products Company Profile Suzhou First Packing Machinery Co.Ltd was founded in 1997.it's the profession design can maker machine manufacturer ,the productions are wildly apply to metal container packing field,such as food,beverage,petroleum,chemical industry,paint,coating,and so on.we are looking forward to your visit for further negotiation and cooperation.Welcome friends from all over the world to visit our company,we will try our best to serve you .

We speacilized in various can making such as:
1-5l round tin canister making line.
1-4l square can making machine.
10-20l cone tank production equipment.
18-20l round can making equipment.
18-20l rectangular tank production line.
Automatic food can production machines. Exhibition Our customers Packing & Delivery
