Ce Certification 1-20L Automatic Tin Canning Machine Tin Can Making Machine Production Line

Product Description Conical Tin Paint Can Making Machine Line

Round Knife Cutting machine
Model	GTIB-15
Max.Thickness	0.5mm
Sheet Width	60-1059mm
Power	1.1kw
Net Weight	1100kg
Dimension	1500x1100x1200mm

Automatic Round Forming Machine
Model	CY400-AT
Diameter range	Φ75-Φ300mm
Thickness	0.5-0.6mm
Max width	430mm
Capacity	20-30cans/min
Net weight	450kg
Dimension	1300x730x1330mm

Can Body Seam Welder
Model	FB2000-A
Power	3N.380V/50Hz 15KVA
Welding speed	≤ 12m/min
Capacity	20~50cans/min
Diameter Range	Φ65~Φ300mm
Height Range	70~ 400mm
Overlap	0.6~1.2mm
Thickness	0.2~0.38mm
Copper wire	Φ1.5 T2
Cooling water	0.3MPa 8-10L/min ≤20℃
Net Weight	1300kg
Dimension	1350×1300×1700mm

Hydraulic Conical Shape Machine
Model	3TD20
Power	5.5KW
Capacity	15-18cans/min
Diameter	210-300mm
Height	270-400mm
Thickness	≤0.5mm
Net Weight	900KG
Dimension	1300x700x1150mm

Hydraulic Per-curling and Flanging Machine
Model	3TB20
Power	5.5KW
Capacity	15-18cans/min
Diameter	210-300mm
Height	270-400mm
Thickness	≤0.5mm
Net Weight	900KG
Dimension	1300x700x1750mm

Pneumatic Can Seamer
Model	GT4A39-R
Power	2.2KW
Can Diameter	Φ210-Φ300mm
Can Height	60-400mm
Capacity	12-16cans/min
Thickness	0.15-0.4mm
Spin rate	1420 revolutions/min
Net Weight	800KG
Dimension	980x580x1900mm

Hydraulic Flanging and Beading Machine
Model	3TC20
Power	5.5KW
Capacity	15-18cans/min
Diameter	210-300mm
Height	270-400mm
Thickness	≤0.5mm
Net Weight	950KG
Dimension	1470x940x1980mm

Our Advantage
♦ MITSUBISH or PANASONIC PLC and variable-frequency speed governor from Japan.
♦ OMRON Sensor and photoelectric switch form Japan.
♦ SMC Waterway detected flow switch from Japan.
♦ SKF bearings from Sweden.
♦ SCHNEIDER electrical appliance components from France.
♦ LG air switch,contactor and circuit breaker from South Korea.
♦ SEMIKRON control thyristors from German.
♦ BOURNS potentiometer from America.
♦ AIRTAC pneumatic components and YONGKUN motor from Taiwan.
♦ KOMPASS hydraulic system from Taiwan.
♦ SHANGHAI BAOSTEEL Cr12MoV material are used in making Moulds.

Detailed Images Our Service 1) one year warranty for the whole system.
2) Free equipment installation and debugging.
3)Atfer one year,we can help you to maintain the machine and accessories are provide only the coat price.
4) We can help you to design the production line ,workshop and provide turn key project.
Packing & Delivery Certifications Our Company Suzhou First Packing Machinery Co.,Ltd. was founded in 1997, it's a professional company which spesialize in designing and manufacturing can making equipments,the products are widely used in food,beverage,petroleum,chemical,paint,coating,ventilation ducts and etc.
about the customer Now, our company's products have been exported to more than 30 countries,like Egypt,Russia,Turkey,Thailand,India,South Africa and so on.
