80Nm^3/hr Nitrogen PSA Generator

 60Nm^3/hr Nitrogen PSA Generator Nitrogen offers a wide range of applications such as purging, firefighter, creating inert atmosphere, carrier gas, blanketing, packing, filling, plastic molding, so on and so forth. PSA  generation is a highly-efficient source of nitrogen,a favorable choice for many manufacturers as it is an easy and reliable way for them to save money and give free control over the nitrogen gas use.    Our company can customize a system to the customer's specifi requirement, optimize it for peak performance and support it with training,maintenance and service.       Wide application scope:

Nitrogen produced by this PSA generator can be used as the protective gas in heat treating process; Chemical industry production, nitrogen filled for purification in all kinds of storage tank and pipeline; Gas for production of rubber and plastic products; Oxygen exclusion and keeping food fresh in food industry package; Purification and blanket gas in beverage industry; Nitrogen filled for package and exclusion of oxygen for container in pharmaceuticals industry; As protective gas in the process of producing electronic component and semiconductor in electronic industry. Purity, flow rate and pressure are stable and can be regulated to satisfy the different customers'needs.

Model	Capacity (Nm³/h)	Feed Gas			Product gas:nitrogen gas
		Pressure (Mpa)	Dew point (°C)	Residual oil (ppm)	Dew point (°C)	Purity (%)	Pressure (Mpa)	Temperature
XRFD98	5-2000	0.7-1.0	≤-17	≤0.003	≤-40	≥98	0.6-0.9	Ambient temperature
XRFD29						≥99
XRFD295						≥99.5
XRFD39						≥99.9
XRFD49						≥99.99


Technological Process

Nitrogen generator system from our company are designed and manufactured based on the technology of Pressure Swing Adsorption(PSA), a mature technology which was developed in Europe in the early 1960s. Ambient air, having being compressed and purified to remove oil, water and dust, enters the adsoption swing adsorping device with two adsorption towers filled with carcon molecular sieve(CMS)  to separate nitrogen gas from the compressed air by absorbing the O2,CO2 and water molecules onto the surface of the CMS while under pressure.When the CMS in the adsorption tower(vessel) becomes saturated with waste gases, the pressure is released and the waste gas is vented through the exhause.The second CMS vessel then begins to make nitrogen, while the first on is regeneration.The cycle usually lasts for about 120 seconds.As the production process is more or less a batch operation, nitrogen storage tank is required to buffer the nitrogen product to ensure the continuous flow through the pipeline to the customer's using point. Nitrogen generation from the PSA sytem usually takes place at a pressure ranging from 75psig to 145psig.     PSA Nitrogen Generation Advantages

The gas seperation of PSA takes such advantages as different gas has different adsorbing capacity in the CMS under different pressure to separate gases. PSA nitrogen generators are designed based on the PSA theory. They possess the properties of simple technology, low space requirement, quick start up, simple maintenance&operation, good applicability, high automation, low operation cost, low investment, etc.

1) convenient and efficient to generate nitrogen: Advance technology, special gas flow distributor to make the gas distribute more well-distributed, high efficient use of CMS, qualified nitrogen can be offered within 15 to 30 minutes.
2) Convenient use: The equipment structure is compact, low space coverage and no need of construction investment, low investment, the only thing to do is to connect power to generate nitrogen.
3) More economical than other ways of nitrogen supply: PSA technology is a simple way to generate nitrogen. It takes air as source, and the only energy consumption is only electricity consumption. So it has the advantages of low operation cost, low energy consumption and high efficiency.
4) Electromechanical integrated design to realize automatic operation: Imported PLC control the full automation, the flow rate, pressure and purity of nitrogen can be regulated and displayed consecutively; No personnel is needed to be on duty.

Enhancement:To ensure the better quality and longer service life, the main parts such as CMS and PLC, we use world famous brand Japan Takeda and MITSUBISHI, for valves, we use Germany Burkert solenoid valves and pneumatic valves.
Delivery Details:
Packaging details: Standard export packaging
Delivery details: Within 60-90days after receipt of the deposit       FAQ   What is the service life of Carbon molecular sieves(CMS)   Usually, for normally use, the life span of the CMS is about 5 to 8 years.   What is the cycle time to replace the filter element? Usually, the filter element needs to be replaced for every 6000 hours.
