Purifying Device after Nitrogen Generator by Carbon Deoxidation

Purifying Device after Nitrogen Generator by Carbon Deoxidation   Acturally, the nitrogen purity produced  directly from the  nitrogen generator is as high as 99.99%.For nitrogen of higher purity, it is better to use the purification device after the nitrogen g enerator. There are several kinds of nitrogen purification devices, here it is Nitrogen Purification by carbon deoxidation. The advantages and characteristics:   When the oxygen content in the feed gas is lower than 5000ppm, carbon deoxidizer is used without hydrogen offered. Carbon fiber, as both carrier and reducer, can directly remove the inert gas and oxygen in the nitrogen. With big capacity of deoxidation and good depth, it is suitable for the circumstance without hydrogen.   Specifications and technical indicators:   Model: XRDC-C
Production rate: 5-3000Nm³/h
Source gas pressure: 0.1-0.6Mpa
Source gas dew point: ≤-10ºC
Oxygen content in gas source: ≤0.5
Product gas(H2) pressure: 0.1-0.6Mpa
Product gas(H2) dew point: ≤-70ºC
Oxygen content in product gas: ≤5ppm
Temperature: Ambient temperature

Model	Capacity (Nm³/h)	Feed Gas			Product Gas:Nitrogen Gas
		Pressure (Mpa)	Dew point (ºC	Oxygen content (%)	Dew point (ºC)	Oxygen content (ppm)	Pressure (Mpa)	Temperature
XRDC-C	5-3000	0.1-0.6	≤-10	≤0.5	≤-70	≤5	0.1-0.6	Ambient temperature

  The flow chart   Application
The nitrogen purification device by carbon deoxidation can be used alone to purify nitrogen, or it can be used followed by PSA Nitrogen generator.   Packaging details: Standard export packaging
Delivery details: Within 60-90days after receipt of the deposit
