12T Diesel Locomotive

12T explosion proof diesel locomotives made in our company were developed for uses in rails as traction power for transportation of coal, non-ferrous mines, nuclear and petrol chemical industries. They can replace present 8T & 12T battery locomotives for transportation in mine and have obvious advantages: 1.    With high quality, reliability and low emission level of imported diesel engine, it has better power supply and assurance with larger power for the locomotive. 2.    With characteristics of diesel engines, power and traction can be kept constant and operated anywhere of mines with high efficiency. 3.    With longer life span for diesel engine, with normal maintenances locomotives can be operated for many years. Its overhaul period shall be beyond 8000 hours. 4.    No charging for diesel engine, cost for charging equipment and station, transformers, independent ventilations can be saved. 5.    Transportation distance with once full charging of fuel is far away and auxiliary transportation time can be reduced. Main technical Data:

Item	Description	CCG10.0/600E(S)	CCG10.0/900E(S)
1	Total Weight	12000kg	12000kg
2	Adhesive Traction	13.72KN	13.72KN
3	Gauge	600mm	750mm
4	Max. Speed(no load)	14km/h	14km/h
5	Max. Speed(rated load)	13km/h	13km/h
6	Min. Passing Curve Radius	7m	7m
7	Axle Distance	1100mm	1100mm
8	Starting Way	Electric or Pneumatic	Electric or Pneumatic
9	Rated Power	66KW	66 KW
10
11	Rated Speed	2200rpm	2200rpm
12	Type of Diesel Engine	Straight in line with 4 Cylinders and 4 Strokes and water cooling system	Straight in line with 4 Cylinders and 4 Strokes and water cooling system
13	Dia. of Cylinder×Stroke	Φ102×120mm	Φ102×120mm
14	Traction Height	270,320,430mm	270,320,430mm
15	Outer Dimension (Length×Width×Height)	4990×1150×1600mm	4990×1400×1600mm
16	Max. Length un-separated	4300 mm	4300 mm
17	Max Traction Tons	169t(Tangent & Straight lines)	169t(Tangent & Straight lines)
18	Prime Diesel Engine	Cummins	Cummins
