HJC longitudinal multi rip saw

Specifications wood ripping saw machine

HJC series multi rip saw line main function is cut big board into small boards;

wood ripping saw machine HJC series multi rip saw line main function is cut big board into small boards;it can work with the front and the back of automatic loading and unloading system to finish automatic feed in and feed out. Main model: HJC12-2 and HJC13-1 and so on. Convenient and safe for operation, it features high efficiency and saving energy.

Technical parameters	Longitudinal multi rip saw
Model	HJC12-1	HJC13-1	HJC12-2
Working width(mm)	1250	1380	1250
Working thickness(mm)	6-25	6-25	6-50
Board straightness(mm/m)	<=0.2	<=0.2	<=0.4
Saw blade outside dia. Inside dia.(mm)	300-80	300-80	300-80/100
Driving motor power(kw)	1.1	1.1	2.2
Feeding speed(m/min)	10-45	10-45	10-45
Main motor power(kw)	11	11	11+15
Spindle rotate speed(r/min)	2930	2930	2930
Working table height(mm)	740	740	950
Weight(T)	2T	2.5T	4T
