hotjin flooring production equipment

Specifications It has different working stations as required,i.e.,precutting, knife jumping,forming,finishing,chamfering and clipping,etc.

flooring production line Wood composite flooring high-speed traverse double end tenoner machine adopts dual-leading-screw to adjust working width freely with a maximum width of 2500mm .It has different working stations as required , i.e., precutting , knife jumping ,forming ,finishing ,chamfering and clipping ,etc. The traverse axis (axis B) is mostly used for forming and processing the ends of multi-layer wood composite floor. It can work with top and bottom saw and jumping knife for trimming and precutting .Additional jumping knife (axis T)may be adopted upon special request.

DTS25-10D+2T		Bamboo&Wood flooring high-speed
		traverse double end tenoner machine
Working width(mm)	400-2500	Rotate speed of cutter shaft(rpm)	6000-7000
Working thickness(mm)	6-18	Power of feeding motor(kw)	3.7
Feeding speed(m/min)	15-30	Gross weight of equipment(kg)	8000
Power of station 1(kw)	3	Axis dia.of station 1-5(mm)	40×75
Power of station 2(kw)	5.5	Sweep-up dia.of cutter cover(mm)	120
Power of station 3(kw)	5.5	Sweep-up dia.of driver chain(mm)	100
Power of station 4(kw)	5.5	Cutter dia.(mm)	200-250
Power of station 5(kw)	3	Height of working surface of table(mm)	950
Power of station 6(kw)	3
Remark:1.D-random axis,T-jumping cutter,the working width can be adjustedto 2.5m,Other specification is upon customer requipment.
2.Our company reserves the right to make further technical improvement.
