LVT floor Double End Tenoner

Specifications Our company is a professional production of LVT floor double end tenoner equipment manufacturer.

Our company is a professional production of  PVC double-endtenoner equipment manufacturers.   Longitudinal Double Chain DET (Model: DTE06-12D)   1. Working width: 100-600 mm 2. Working thickness: 4-20 mm 3. Height of working surface of table: 1100(Mainframe All Height 1100 mm) 4. Rotate speed of cutter shaft: 6000-7000 rpm 5. Feeding speed: 30-80 m/min           6. Motor Power: DTE06-12D Station 1, 2 main spindle motor:    4X8 KW Stations 3,4,5,6 milling spindles: 8X5.5 KW 7. Feed-in Motor:               7.5   KW 8. Cutting Tool Diameter: Φ250-Φ280XΦ40           Cutting tools such as compact sets up a hydraulic motor in need of special note. To ensure 80 meters per minute processing capacity, the proposed use of hydraulic sets up tight. 9. Dust Absorbing Inlet Diameter Stations 1, 2 , 3 , 4 ,5,6: Φ120mmX12 Transmission chain dust absorbing: Φ100mm 10. Weight:        9000 KG   Transverse Double End Tenoner Machine (DTEH18-12D)

1. Working length: 600-1500 mm (special configuration working length:400-2500mm) 2. Working Width: 120-600 mm 3.  Working thickness: 4-20 mm 4. Height of working surface of table: 950 mm (Mainframe All Height 1100 mm) 5. Rotate speed of cutter shaft: 6000-7000 rpm 6. Feeding Speed: 15-40 m/min  7.Motor Power: Station 1, 2 ,3,4,5,6 milling spindles: 6X5.5   KW; 4 X3KW              Feed-in motor:          3.7   KW              Width adjusting motor: 1.1   KW 8.Cutting Tool Diameter:Φ220-Φ250XΦ40    Cutting tools such as compact sets up a hydraulic motor in need of special note. 9.Dust absorbing inlet diameter:      Stations 1, 2, 3, 4, 5,6:           Φ120mmX12 Transmission chain dust absorbing: Φ100mmX2 10.Weight:       9500 KG   Please contact us if you have other special requirements or configurations.
