Double Chain Hi-Rate Double End Tenoner

Specifications Double Chain Hi-Rate Double End Tenoner has gained good application in laminate flooring and wood composite flooring production

         DTLSseries longitudinal double chain and double end tenoner machine, featuring high-precision feeding chains, built-in compressor, adjustable pressure, wide working range, has high speed ,large capacity and high precision, therefore, it has gained good application in laminate flooring production and wide application in the wood composite flooring production as well, owning evident advantages in the processing of sinomenine floor. Since it can use pointless die-block ,no scratch or damage will be made to the floor.

DTLS
Min.working width(mm)	120	Power of station 5(kw)	3
Working thickness(mm)	6-18	Max.working width(mm)	500-600
Rotate speed of cutter shaft(rpm)	6000-7000	Shaft dia.(mm)	40×75
Power of feeding motor(kw)	5.5	Cutter dia.(mm)	220-250
Feeding speed(m/min)	30-60	Gross weight of equipment(kg)	8000
Power of station 1(kw)	5.5	Sweep-up dia.of cutter cover(mm)	120
Power of station 2(kw)	5.5	Sweep-up dia.of driver chain(mm)	100
Power of station 3(kw)	8	Height of working surface of table(mm)	1100
Power of station 4(kw)	3
Max.insert depth(mm)	5/7/12(17)Feeding speed adjustable to milling volume
Remark: 1.Our company reserves the right to make further technical improvement.
