Carbonated drink filling Machine

Specifications Carbonated drink filling Machine

1.Fully automatic

2.speed:2000-30000bph

3.PLC control

4.Fill carbonated drink

 Carbonated drink filling Machine
1.Fully automatic
2.speed:2000-30000bph
3.PLC control
4.Fill carbonated drink    carbonated drink filling machine It is suitable for packing drink containing gas.carbonated drink filling machine is mainly used for filling carbonated drink, cola etc. with pet bottle or glass bottle MODELS:

Model	CGFD16126	CGFD18186	CGFD24248	CGFD32328	CGFD404010	CGFD505012	CGFD606015	CGFD808020
Filler/Capper heads	16-12-6	18-18-6	24-24-8	32-32-8	40-40-10	50-50-12	60-60-15	80-80-20
Bottle diameter(mm)	Diameter=50-100 H=170 330-1500ml			Diameter= 50-110   H= 160-340
Production capacity (b/h) 350ml	2000-4000	4000-6000	8000-10000	10000-12500	12500-15000	16000-20000	20000-24000	26000-32000
Filling temperature(Celsius)	0-5
Filler type	Balanced pressure filler
Spraying pressure	0.2-0.25			0.2-0.25
Filling pressure	0.15-0.35	0.15-0.35	0.15-0.35	0.2-0.4	0.2-0.4	0.2-0.4	0.2-0.4	0.2-0.4
Motor power	2.2+0.55+0.12	2.2+0.55+0.18	3+0.55+0.18	5.5+0.55+0.18	7.5	11	15	19
Overall dimension(L*W*H)mm	2300*1600*2500	2600*1920*2550	3100*2200*2800	3850*3000*2850	4850*3800*2750	5750*3550*2750	6500*5500*2750	7680*6640*2650
Weight (kg)	2800	3650	4800	6800	8650	10500	12800	15000
