Bottle Washer Filler and Sealer

Specifications Bottle Washer Filler and Sealer

Production capacity:200-240 BPH

  This filling line specially produces gallons bottled drinking water, whose types (b/h) are: 100 type, 200 type, 300 type, 450 type, 600 type, 900 type, 1200 type and 2000 type.   It interates bottle washer, filler and sealer into one unit, in order to achieve the purpose of multiple injections of washing and sterilizing by means of liquid washing and bleaching are used in bottle washer. Washing solution can bo used circularly. The sealer can seal bottle caps automatically carry out bottle feeding, washing, sterilizing, filling, capping, counting and products discharging.   The Bottle Washer Filler and Sealer line is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.

Model	QGF-100	QGF-300	QGF-450	QGF-600	QGF-900	QGF-  1200	QGF-2000
Filling heads	1	2	3	4	8	12	16
Volume(L)	18.9
Barrel size(mm)	φ 270*490
Capacity(bucket/n)	100-120	200-240	300-400	600	900	1200	2000
Gas proessure(mpa)	0.4-0.6	0.4-0.6	0.6	0.6	0.6	0.6	0.6
Gas consumption(m3/min)	0.37	0.6	0.6	1.2	2.2	3	4.5
Motor power(kw)	1.75	3.22	4.8	8.5	8.5	8.5	8.5
Rated voltage(V)	380V/50Hz
Outline dimension(mm)	3790*650*1550	3550*800*1800 2800*1100*1800	3550*1200*1800 3800*1100*1800	3650*1500*1800 3800*1100*1800	2200*1860*2700 Excluding cleaning	2560*2350*2750 Excluding cleaning	3100*2800*2750 Excluding cleaning
Weight(kg)	800	2800	4000	5500	7500	9500	11800
