CO2 Generator machine

Get Latest Price

Delivery Time:: 30 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Jiangsu, China (Mainland)

Product Description

Specifications CO2 Generator machine

1.generating the pure co2

2.minimum output:26kg/h

CO2 Generator machine introduce 1.CO2 generator machine can very quickly get CO2; it contain the filter device 2.Provide for carbonated drinks production Line. 3.This generator machine is suitable for middle-small type of carbonated drinks Factory. CO2 Generator machine technical parameter

NaHCO3	purity≥99% max feeding capacity:150kg/time
concentrated sulphuric	purity≥98% max feeding capacity90kg/time
CO2 Production	purity≥99% normal conditions Max39.6m3
pressure of Compressed gas (adjustable)	6-7kg/cm2
Sulfuric acid cylinder total volume	60lts
Reactor	total volume :300lts (straight ), operating pressure(MPa): normal pressure, operating temperature: <80°C
mixer	power:0.75kw, mixing speed:16.66 rpm, ReducerModel:BLY12-87-0.75
diaphragm metering pump(adjustable)	power supply:~380V(three phase), operating pressure(MPa):0.3~1.0 Mpa
air compressor	volume:0.22m3/minute, pressure:0.7MPa
Gas purification unit	Operating pressure(MPa):0.8MPa, operating temperature:<50°C, measurement range of Flowmeter:0.6~6 m3/h(gas)
whole power	3.20kw
Appearance size(mm)	5800×1800×2500mm
