Elevator Anchor Bolt, Lift Gecko, Elevator fastener

Specifications Elevator Anchor Bolt, Lift Gecko, Elevator fastener

1For Rail Bracket Installation

2.Various specifications available

Anchor Bolt, Elevator gecko, Elevator fastener, Anchor Bolt with Nuts and Washers,Lift fastener, Lift Anchor Bolt with Nuts and Washers   Elevator Anchor Bolt, Elevator Gecko, Elevator Fastener Nova has been mainly supplying high quality TypeA and Type F Elevator Anchor Bolt according to customers' request  in big volume every year. 1.TypeA Elevator Anchor Bolt / Gecko

Order Code	Specification	Diameter	Sleeve Length	Drill Diameter	Pull Out Load(kgs)
NV-650	M6*50	9.5	30	9.5	890
NV-865	M8*65	12	35	12	1390
NV-870	M8*70	12	35	12
NV-1070	M10*70	14	40	14.5	1600
NV-1080	M10*80	14	40	14.5
NV-1010	M10*100	14	40	14.5
NV-1012	M10*120	14	40	14.5
NV-1210	M12*100	17.3	50	18	2540
NV-1212	M12*120	17.3	50	18
NV-1215	M12*150	17.3	50	18
NV-1220	M12*200	17.3	50	18
NV-1610	M16*100	21.7	50	22	3300
NV-1612	M16*120	21.7	60	22
NV-1615	M16*150	21.7	60	22
NV-1620	M16*200	21.7	60	22
NV-2016	M20*160	25.4	80	26	4950
NV-2020	M20*200	25.4	80	26
NV-2216	M22*160	28.6	90	29	6400
NV-2420	M24*200	31.8	110	33.1	8640

2.TypeF Elevator Anchor Bolt / Gecko

Nova Code	Anchor Size	Thread Length	Min. Embedment	Quantity Box/Ctn
NV14F-640	M6*40	18	27	200/1000
NV14F-655	M6*55	25	35	200/1000
NV14F-670	M6*70	25	35	200/1000
NV14F-695	M6*95	25	35	200/1000
NV14F-850	M8*50	25	35	200/1000
NV14F-865	M8*65	25	40	200/1000
NV14F-880	M8*80	25	40	200/1000
NV14F-895	M8*95	25	40	100/500
NV14F-8105	M8*105	25	40	100/500
NV14F-8120	M8*120	25	40	100/500
NV14F-8165	M8*165	25	40	100/500
NV14F-8220	M8*220	30	40	100/500
NV14F-1065	M10*65	30	40	100/500
NV14F-1080	M10*80	30	50	100/500
NV14F-1095	M10*95	30	50	100/500
NV14F-10115	M10*115	30	50	50/250
NV14F-10120	M10*120	30	50	50/250
NV14F-10130	M10*130	30	50	50/250
NV14F-1280	M12*80	40	50	50/250
NV14F-12100	M12*100	40	60	50/250
NV14F-12120	M12*120	40	60	40/200
NV14F-12135	M12*135	40	60	40/200
NV14F-12150	M12*150	40	60	25/125
NV14F-16105	M16*105	60	70	25/125
NV14F-16140	M16*140	60	80	25/125
NV14F-16180	M16*180	60	80	25/125
NV14F-14F20	M16*220	60	80	25/125
NV14F-20125	M20*125	65	85	20/100
NV14F-20160	M20*160	65	100	20/100
NV14F-20220	M20*220	65	100	10/50
NV14F-20300	M20*300	65	100	10/50

Nova welcomes you to visit our website forits more technical specifications or email us to get our elevator anchor boltpreliminary inquiry sheet for your selection.
