RISUN Low-E Double Layer Solar PV Module
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Jiangsu, China (Mainland) |
|---|
| Module Conf.
| Reflect color | Visible Light | PV Power | U-value (Diathermanous Coefficient) | Sunshade Coefficient | Wp/m2 Module Max Power | |||
| Transparncy Ratio | Reflect Ratio | Transparency Ratio | Reflect Ratio | Argon Sweep Gas | No Argon Sweep Gas | ||||
| 8mm Low-E Tempered Glass +12A+6mm PV Module | Silver | 1 | 11 | 2 | 12 | 1.38 | 1.68 | 0.16 | 80~120 |
| 8mm Low-E Tempered Glass +12A+6mm PV Module | Silver Blue | 6 | 10 | 7 | 10 | 1.42 | 1.72 | 0.24 | 80~120 |
| 8mm Low-E Tempered Glass +12A+6mm PV Module | Silver Blue | 8 | 10 | 9 | 10 | 1.53 | 1.81 | 0.26 | 80~120 |
| 8mm Low-E Tempered Glass +12A+6mm PV Module | Green | 6 | 10 | 5 | 10 | 1.53 | 1.81 | 0.21 | 80~120 |
| 6mm Thermal Reflectance Coating and Tempered Glass +12A+8mm PV Module | Silver | 1 | 11 | 1 | 11 | 2.01 | 2.24 | 0.21 | 80~120 |
| 6mm Thermal Reflectance Coating and Tempered Glass +12A+8mm PV Module | Silver Blue | 7 | 10 | 8 | 9 | 2.44 | 2.62 | 0.29 | 80~120 |
| 6mm Thermal Reflectance Coating and Tempered Glass +12A+8mm PV Module | Super Clear | 10 | 10 | 15 | 9 | 2.52 | 2.69 | 0.33 | 80~120 |
Module | Structure | glass+PVB film +cell chip array+glass |
Size | Min300mm×300 m Max2246mm×1124mm
| |
Efficiency | 6%-14% | |
Cell | Type | Monocrystalline polycrystalline |
Color | Blue Gray Black | |
Efficiency | monocrystalline 15-21% | |
Front Glass | Type | Low iron ultra clear glass |
Figured glass | ||
Back of the Glass | Color | Blue Brown Golden Green |
Connection Type | Position of junction box:back/side | |
