Competitive price high reliability 15W poly solar panels

Specifications

ITEM NO	RSM36-156P/15W
Maximum Power(W)	15W
Maximum Power Voltage(Vmp)	17.4V
Maximum Power Current(Imp)	0.86A
Open Circuit Voltage(Voc)	21.6V
Short Circuit Current(ISC)	0.95A
Maximum System Voltage	715V
Power Tolerrance	±5%
Maximum Series Fuse Rating	8A
Temperature coefficient  of ISC	–0,04%/°C
Temperature coefficient  of VOC	–0.38 %/°C
Temperature coefficient  of P Max	–0.47 %/°C
Warranty	90% of 10 years, 80% of 25 years
Standard Test Comditions	AM1.5  1000W/m2 25°C+/-2°C
Cable	Electrical cable of 0.4mm2   (CLASS II)
Size of Module(mm)	400*340*23mm
Solar Cell	156*156 Polycrstalline
Backing(Material)	TPT
Temperature Range	-40°C to +85°C
Frame(Material Corners,etc.)	Aluminum-Alloy
Number of Cell(PCS)	36=2*18pcs
Weight(Kg)	1.8Kg
Tolerance Wattage(e.g.+/-5%)	±3%
Front Glass Thickness(mm)	3.2
Surface Maximum Load Capacity	2400Pa
Allowable Hail Load	23m/s, 7.53g
Packing	10PCS/ 340*400*18
Container loading	5600PCS
	11200PCS
	13600PCS

      Features  1. High cell efficiency with quality silicon materials for long term output stability    2. Strictly quality control ensure the stability and reliability, totally 23 QC procedures    3. High transmittance low iron tempered glass with enhanced stiffness and impact resistance    4. Both Polycrystalline and Monocrystalline    5. Excellent performance in harsh weather    6. Outstanding electrical performance under high temperature and low irradiance    Quality assurance testing Thermal cycling test   Thermal shock test   Thermal/Freezing and high humidity cycling test   Electrical isolation test   Hail impact test   Mechanical, wind and twist loading test   Salt mist test   Light and water-exposure test   Moist carbon dioxide/sulphur dioxide        Any question please ask me feel free, and please add me Skyp:huxiaoxia88
