Vertical milling machine

PRODUCT NAME:Vertical milling machine   SPECIFICATIONS:

Item		Units	X5040
Table	Table size	mm	400*1700/2000/2200
	No.of T-slots		3
	Width of T-slots	mm	18
	Max load	kg	800
	Distance between T-slots	mm	90
Travel	Longitudinal travel(manual/auto)	mm	900/880,1200/1180,1380/1360
	Cross travel(manual/auto)	mm	315/300
	Vertical travel(manual/auto)	mm	385/365
Spindle	Spindle taper		7:24(ISO NO.50)
	Spindle bore diameter	mm	29
	Spindle speed range	r/min	30-1500
	Spindle speed step	steps	18
	Axial mootion	mm	85
	Max.swivel angle of spindle		±45
	Distance from spindle nose and table surface min/max.	mm	30/500
	Distance from centre line of spindle to vertical guideway surface of column	mm	450
Feedrate	Cutting feed rate	mm/min	X:23.5-1180,Y:15-786,Z:8-394
	Rapid feed rate	mm/min	X:2300,Y:1540,Z:770
	NO. of feed	mm	18
Motor	Power of spindle motor	kw	11
	Power of feed motor	kw	3
Others	Overall dimensions(LxWxH)	mm	2556X2159X2258
	Net weight	kg	4250

    STANDARD ACCESSORIES: wrenches,drawbar,sleeves, morse taper intermediate sleeve, foundation bolts ,nuts, washers,oil gun, lump ,spring,brush core,end mill arbor,spanner for end mill cutter arbor     OPTIONAL ACCESSORIES(charge separately): deviding head, DRO(for two axis or three axis), machine vise,rotary table,milling chuck,boring cutter holder, facing cutter,vertical mill cutter,etc.   WHY CHOOSE US?   We are the MANUFACTURER of high quality milling machine with competitive price!   Such as vertical milling machine X5040/X5032, universal horizontal milling machine  X6140/X6132,radial milling machine X6330, etc.   The  sales performance, satisfied accessories,longtime work team experience, stability & durability of the machines are our best selling points!

Company Brief Nantong Lecroy Machine Tool Manufacturing Co,.Ltd specializes in machine tool research and development, design, manufacturer and sales. We have a long history to produce precision machine tool.
Assembly shop of vertical machining center   We follow strict assembly technique after we check each parts are eligible.
Assembly shop
Warehouse
Casting
The main parts   gear
