Elevator Push Button Red Light

$3.00 - $5.00/piece

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Thanks for choosing HITECH ELEVATOR as your business partner

We can provide all types of push button.

1.Slim design

2.Anti-vantal

3.Big size,dual light,touch

4.Bus wiring push button

5-wire bus conection, save wiring cost, improve installation efficiency

6-Surface with stainless steel, translucent display.(Braille available)

7,The usual lighting color of button is red,however blue, green, while are optional

8.Installed by screw structure,suitable for 2-6mm panel.

9. Signal type: 'digits','up','down','close','open','alarm','intercom' and so on.

Electrical Properties	Indication light	Rated Voltage(optional)	DC12V,DC24V
		Rated Current	less than 30mA
	switch	Rated Voltage	DC24V
		Rated Current	50mA
		Contact Resistance	less than100mΩ
		Insulation Resistance	more than 100mΩ
Mechanical Properties	Operation Distance		0.3-0.7mm
	Maximum Distance		0.8mm
	Operation Pressure		3-6N
	Life-Span		more than1 millions of operaration
Operating Environment	Operating Temperature		-10 to 50 centigrade(no iceing)
	Operating Humidity		45%-90%
