aluminum insulation material

Antiglare heat insulation/ high duty sarking       Description       The material provides excellent insulation: reflects up to 97% of radiant energy in addition to resisting other types of heat transfer from conduction,convection,and radiation.The side of metalized PET/Alu forms an effective barrier against moisture,air currents and vapors.It is economical solution in many field.     Specification:

Product Name	Antiglare heat insulation/ high duty sarking
Main Material	Pure Aluminium Foil / Metalised PET Film & PE Woven
Material Structure	Alu + woven  Alu + woven +  Alu                                       Metalised PET Film+Woven Metalised PET Film+Woven+Metalised PET Film
Woven Weight	usually 60gsm /65gsm
Coating Color	Blue, Green, Pink, Orange or customized
MPET/ Pure Aluminium Foil Thickness:	12micron/7 micron
Product Thickness:	0.14-0.18mm
Reflectivity:	96%~97%
Normal Roll size:	1.2m *50m/roll; 1.2*100m/roll;  can be customized
Packing:	1 roll/ clear plastic bag or customized logo printing packing bag accept

   Function:     1.Water, corrosion, light can be prevented effectively.   2.for keeping  warm ground, warm wall, moisture-proof floor,  etc.   3.Eco-friendly .insulation,.water-proof,oil resistant, etc.   4.For construction,OEM is available.       Tech Data

Material Structure:     AL/ woven cloth/AL
Roll Width:1.2m*100m (lenth can be customized)
PROPERTIES	TEST DATA	UNIT
Thickness		mm
Weight	183	g/m2
Emissivity	0.08-0.09	COEF
Thermal conductivity	0.036	w/m0
Apparent Density	73	kg/m2
Reflectivity	91-92	%
Water Vapour Transmission	0.015	g/m2kpa
Corrosion	doesn't generate
Tensile Strength(MD)	14.65	Mpa
Tensile Strength(TD)	17.50	Mpa

  Installation Picture     Produce Process     Packing And Delivery       Test Report       Company View       Related Products
