Aluminum radiant insulation reflective aluminum insulation

Aluminum radiant insulation reflective aluminum insulation

Get Latest Price

Delivery Time:: 15 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Jiangsu, China (Mainland)

Product Description

Aluminum radiant insulation reflective aluminum insulation The material provides excellent insulation: reflects up to 97% of radiant energy in addition to resisting other types of heat transfer from conduction,convection,and radiation.The side of metalized PET/Alu forms an effective barrier against moisture,air currents and vapors.It is economical solution in many field.

Product description

Item	Aluminium foil+ woven fabric+ Aluminium foil
Thickness	0.14-8mm
Roll Width	1.2m
Roll Length	50--6000m
Available grade	plain lacquered, heat sealable
Characteristics	High gloss, perfect stiffness, excellent barrier property, proer brightness, excellent ink adhesion,
Packing	by PE bag, bulk on container. Diameter of internal paper core of rolls: 1.5 "or 3 "
Application	(1),Roof,Attic,Underlay & floor InsulationUnder Concrete & wood. (2),Crawl Space,Stud Wall,Metal Frame Building Insulation
Payment Term	By T/T, 30% as prepayment, the balance will be paid before loading containers after production
Delivery Time	Containers can be loaded within 20 days on receipt of prepayment

Function: 1.Water, corrosion, light can be prevented effectively. 2.for keeping warm ground, warm wall, moisture-proof floor, etc. 3.Eco-friendly .insulation,.water-proof,oil resistant, etc. 4.For construction,OEM is available.

Tech Data

Material Structure: AL/ woven cloth/AL
Roll Width:1.2m*100m (lenth can be customized)
PROPERTIES	TEST DATA	UNIT
Thickness		mm
Weight	183	g/m2
Emissivity	0.08-0.09	COEF
Thermal conductivity	0.036	w/m0
Apparent Density	73	kg/m2
Reflectivity	91-92	%
Water Vapour Transmission	0.015	g/m2kpa
Corrosion	doesn't generate
Tensile Strength(MD)	14.65	Mpa
Tensile Strength(TD)	17.50	Mpa
