XPE Foam foil insulation/reflective foil thermal insulation/heat insulations

  Foam foil fire resistant heat insulation        Aluminium foil bubble XPE foam bubble foil insulation  Brief Introduction:   Star Thermal Break 6.0/6.5/8.0 is a waterproof/fireproof/soundproof three-in-one reflective insulation, thermal break and vapour barrier suitable for use in roofs, walls and floors. It is a fibre-free, non-allergenic product, made from high density XPE foam.   When incorporated into typical construction systems a superior thermal performance can be achieved. When installed facing an air space, StarThermal Break6.0/6.5/ 8.0 is a barrier to radiant heat, enhancing the energy performance and thermal comfort of a building, while providing a physical layer to protect against water and air infiltration


Thermal Break Insulation Benefits:

1. Heat laminated, foam core providing an exceptional barrier against conductive heat, humidity, water and vapour penetration
2. Two outer layers of 99%+ pure aluminium (with reinforced weave/scrim on both sides)
3. Reflecting up to 97% of radiant heat
4. Excellent fire properties,Meets AS1530.2 thermal break requirement in steel frame construction
5. Excellent acoustic properties
6. Environmentally/Eco friendly and fibre-free
7. Anti-slip properties make it safer for installers
8. Compliance with the latest insulation standards
9. 30m2 roll (1350mm x 22.25m)

Product Name	high quality radiant barrier insulation
Main Material	Pure Aluminum Foil / Metalized Film & Closed Cell EPE / XPE Foam
Material Structure	MPET + EPE / XPE                                    MPET + EPE / XPE + MPET Alu + EPE / XPE Alu + EPE / XPE + Alu  Alu + woven + EPE / XPE + Alu                                                  Alu + woven + EPE / XPE + woven + Alu  Alu + woven + EPE / XPE + Anti-glare coating Alu  Alu + EPE / XPE + woven + Anti-glare coating Alu
Normal Foam Thickness	4mm, 5mm, 6mm, 6.5mm, 8mm
Coating Color	Blue, Green, Pink, Orange, Oliver or customized
MPET/ Pure AL Thickness	12micron / 7 OR 9 micron
Product Thickness	1mm-25mm
Reflectivity	95%~97%
Normal Roll size	1.2m *30m/roll ; 1.2m *40m/roll; 1.35m *22.25m/roll; can be customized
Packing	1 roll/ clear plastic bag or customized logo printing packing bag accept

Products Details:       Thermal Break Insulation Data Sheets:

Material Structure:      AL/XPE(EPE)/ AL ( foam thickness can be customized )
Roll Width:1.2m (lenth can be customized)
PROPERTIES	TEST DATA	UNIT
Thickness	6	mm
Weight	325	GSM
Emissivity	0.03-0.04	COEF
Apparent Density	135	kg/m3
Reflectivity	96-97	%
Water Vapour Transmission	0.010	g/m2kpa
Corrosion	doesn't generate
R-Value	4.831	M2.k/w
Tensile Strength(MD)	0.81	Mpa
Tensile Strength(TD)	1.48	Mpa

  Installation Application:  l  Roof,wall,floor l  Shells of air conditioner and water heater l  Protective coating of water pipe amd ventilating pipe   Installation Pictures:       Production Line   Packing & Loading       Test Report     Factory View       Related Products
