Most Popular Plastic Cup Water Filling And Sealing Machine

Our Company COMPANY PROFILE:  Located in Zhangjiagang City of Suzhou, It is nearby to shanghai port and wuxi airport, it is eary to ship and customers visiting.
AQUA-Filling provides various technical services to help users design equipment layout, answer users' consultation, train users' staff and provide practical operation guidance.

Product Description Product Application 1.This machine is a multifunctional high-speed fully automatic machine specially designed for liquid or semi-liquid(such as water, milk, yogurt, olive oil, fruit juice, tomato sauce, honey) to be filled and sealed.
2. The machine applied with world famous electrical and pneumatic components. High quality, high stability, long service life. All the parts of machine are made of food grade #304 stainless steel.

Cup Water Filling And Sealing Machine
Model	CP-10
Filling heads	10
Capacity	10000 cups per hour
filling volume	30-300ml
Bottle Height	150~310mm
power source	380v 50hz 3 phase
Motor power	5.5kw
Size	3800*1000*1900 mm
Weight	1400kg

Main Features This machine is a multifunctional high-speed full automatic machine specially designed for liquid or semi-liquid(such as water, milk, yogurt, olive oil, fruit juice, tomato sauce, honey) to be filled and sealed. The machine applied with world famous electrical and pneumatic components. High quality, high stability, long service life. All the parts of machine are made of food grade #304 stainless steel.

1. Advanced design, reasonable structure, reliable performance;

2. Fully automatic operation, adjustable production speed, easy operation, safety, increase productivity, reduce labor costs;

3. Photoelectric sensor track ensure accurate sealing;

4. Twice sealing, sealing pressure can be adjusted according to customer requirements as easy or difficult to tear, reflecting greater humanization design;

5. Seal firmly and smooth flawless;

6. Customize equipment according to the customer requirements and other accessibility features;

7. Configuration: this machine uses the channel steel, welded together, after 3 times anti-rust treatment, outsourcing #304 stainless steel. Exposed parts are made of rust-proof handle.
Detailed Images A.Machine parts Name: filling part Brand: Aqua Original: China 1.  All 304 stainless steel filling heads . B. Machine Parts Name: sealing part
Brand: Aqua
Original: China  1.All 304 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean
2.No cup no filling
C.Machine Parts Name: control part
Brand: Aqua
Original:  China
1PLC control, adjust the speed according to customer;s requirement
D. Machine Parts Name: cup water filling machine
Brand: Aqua
Original: China
This machine integrates filling sealing printer in one set
Packing & Delivery

Packaging
Size	123 (L) * 456 (W) * 789 (D)
Weight	1.2 T
Packaging Details	we use wooden case package outside, PE film package inside, standard exported package, or based on customer's requirement.
