Basic Info

Product Description

Zhangjiagang Aqua Machinery Co.,Ltd

Zhangjiagang Aqua Machinery Co., Ltd. is a professional manufacturer of beverage machinery in China.Our main products have:

Alkaline water Ionizer system

Water treatment system

Water filling production line

Juice filling production line

Carbonated drinks production line

Aerosol filling machine

5 Gallon bottle filling production line,

and all other auxiliary equipment.

Our engineers are located all over the world and can provide safe and fast service to your beverage production solutions in your country.

Product Overview

Homemade patented electrolyzer Ionized Alkaline water Plant / bottling Alkaline Water Plant

1. The human body fluid is between 7.34 and 7.45, and the alkaline water pH is between 7 and 10, which meets the needs of the human body's weak alkaline environment, neutralizes the acidic toxins in the body, and maintains the body's acid-base balance.

2.In general tap water, the potential value of mountain spring water is +200mv+500mv, and the redox localization of alkaline reduced water is reversed from +500mv to -150mv-350mv as negative value. Because of the high cation content of positive potential in water, it can enter the body. Quickly capture acidic substances with negative potential, combine them and then excrete with water. It plays a role in removing garbage from the body and contributes to the reduction of "excess free radicals"

3.The water contains a proper amount of minerals and trace elements, and it is in the form of ions, suitable for human body washing and beneficial to human health.

Descerption of our alkaline water ionizer

1/ industrial Type, Smallest one 1000LPH2/ Feeding water conductivity should be beweten 80-240 μs/cm
3.Feeding water and alkaline water ration: 2:1
4,Material : SUS 304
5 With precision filter together

PRODUCT SPECIFICATIONS

Industrial Type Alkaline Water Electrolyzer / Commercial Alkaline water IonizerProduct Name	Homemade patented electrolyzer Ionized Alkaline water Plant / bottling Alkaline Water Plant
Inflow pressure :	0.05~0.15MPa
Power supply:	380v 50HZ 3 Phase
Outflow rate:	Smallest 60L/H
Productive way:	continuous electrolysis
PH value:	7-10 Adjustment
Power	3 KW
Weight	300KG
Machine size	100010001800MM（LHW）
Inelt water requirement	Conductivity 80-240μs/cm
Electrolyte	Nacl or Hcl

Item	Main Component	Brand
System function	Brief	Industrial-grade equipment can run 24 hours a day without interruption, automatic alarm and shutdown when there is insufficient raw water, acid or alkali water full. Key indicators such as pH value are displayed in real time through online meters.
Electrical and Automation Control	Breaker	ABB
		AC contactor	ABB
		VFD	ABB
		PLC	Siemens
		Touch screen	Siemens
		Terminals	PHOENIX
		Cable	LAPP
		Level Switch	Taiwan Radar
Electrolysis device	Electrolyze	Titanium platinum alloy plate (Our Patent)
Electrolysis device		Electrolytic power supply	Customized military grade
Waterway valve	Stainless steel valve	304 Stainless steel(Shangdong Public company)
Waterway valve		UPVC pipes	Food grade，Fromosa Plastics(top company from Taiwan)
Online meter	Inlet conductivity	Create From China(Public Company)
Online meter		Outlet pH	Create From China(Public Company)
Dosing system	Dosing pump	SEKO From Italy
Dosing system		box	PE
Control cabinet	304 stainless steel	Aqua
Water treatment cabinet	304 stainless steel	Aqua

Successful Project

Project in South Korea

Project in China

one of the biggest water supplier

Project in indonesia

Application

Food Beverage

There are a lot of pesticide residues in vegetables and fruits. The use of alkaline water can effectively remove these residues. At the same time, alkaline electrolyzed water is harmless to the food itself.

Food industrial

Marine product storage and preservation

Cleaning of Marine product processing equipment and utensils

Breeding environment and utensil disinfection

Livestock drinking water.

Slightly acidic electrolyzed water is pumped into the pipeline and directly used by livestock and poultry, which can effectively play a role in disinfection and sterilization.

Restaurants and Feeding Industry

Strongly electrolyzed water can kill all kinds of bacterial such as E.coil. Staphylococcus aureus, salmonella,vibrio parahaemolyticus and etc,

Medical instrument

you can sterilize many kinds of bacterial on the surface of medical tools and prevent infection from the tools

Restaurants / feeding facilities

It solves the hygiene problems in the slaughter house by sterilizing floor and facilities and deodorizing smells of blood and rotten meats

Alkaline water ionizer Machine

1/ PH 7-10 drinking Alkaline water

2/ 1000LPH smallest production

3/ To making drinking Alkaline water with safe technology, doesn't add any chemical to Adjust PH , only by ionizer

Hydrogen rich ionizer machine

1/ to make hydrogen water, Dual-core electrolysis

2/PH 7-10 Ajustment

3/OPR depends on customer

4/Hydrogen content normally 1.2-1.6ppm, but we can customize.

Strong Acid / alkaline machine

1. to make PH 12-14 Alkaline water

2. Function: Used to clean food, industrial, sterilize,agriculture ,medical etc.

Q1：Why Choose US

A1: We made the industrial type alkaline water ionizer machine.the quality is the top in ionizer industrial. We do not need more maintenance cost, cause our machine is very stable.

Q2: Why your price is higher than others ?

A2: At first pls check the appearance of our machine, we are industrial type not commercial or household, our machine stability, life time, technology, configuration of the machine are not in the same level.

Q3: You also mentioned that you are the industrial Type not Commercial type, what is that meaning ?

A3: commercial type equipment with lost cost, so it can be accepted by people in the market, like the air conditioner, it is necessary for each family, but we only used a quarter of a year ; Likes the air conditioner in the supermarket, it will be used 80% in a year. Alternate use of cooling and heating modes, so the parts in side required high level, the life time should be longer, the quality should better, and required higher stability, Cause market is a public place, it is very important for them, but if you used a household machine into commercial usage, it will be broken soon, and the efficient is lower.
