PH 9 Automatic Weak Alkaline Electrolyte Water Machine / Ionized Alkaline Water Plant

PH 9 Automatic Weak Alkaline Electrolyte Water Machine / Ionized Alkaline Water Plant

$21800.00

≥1 set

Min. Order:: 1 set

Min. Order:: 1 set

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Overview

PH 9 Automatic Weak alkaline electrolyte water machine / Ionized alkaline water plant

Electrolysis principle of weak alkaline electrolyzed water generator series 1. Pure physical decomposition method, no minerals are added to the water (such as various mineral stones, alkaline balls, tourmaline and other substances). 2. The purified tap water passes through the electrolytic cell of the electrolytic separation equipment with direct current (based on the principle of like charges repel and opposite charges attract), which will collect the positively charged cations such as calcium, potassium, magnesium, sodium, etc. in the water to the cathode to become alkaline electrolytic reduced water with a (-) potential; while the negatively charged anions such as chlorine, trihalomethanes, phosphoric acid, sulfuric acid, nitric acid, etc. are collected at the anode to become acidic oxidized water with a (+) potential. During the electrogenerated ion exchange, due to the action of the electric field, the free cations such as calcium, magnesium, potassium, sodium in the water move to the negative electrode side, increasing the content of trace elements beneficial to the human body in the alkaline water on the negative electrode side, and these beneficial elements exist in the form of ions, which are more suitable for human absorption. The harmful substances in the raw water have been discharged with the acidic water.

Descerption of our alkaline water ionizer

Inflow pressure :0.15~0.35MPa
Power supply:380V 50HZ
Inflow temperature:10~40 degree
Outflow rate:1T/H~100T/H
Productive way:continuous electrolysis
Value of PH:alkaline 7.0~10.0
The portion of acid and alkaline:the maximum adjustment ratio 3:7

PRODUCT SPECIFICATIONS

Product Name	PH 9 Automatic Weak alkaline electrolyte water machine / Ionized alkaline water plant
Inflow pressure :	0.05~0.15MPa
Power supply:	380v 50HZ 3 Phase
Outflow rate:	Smallest 60L/H
Productive way:	continuous electrolysis
PH value:	7-10 Adjustment
Power	3 KW
Weight	300KG
Machine size	100010001800MM（LHW）
Inelt water requirement	Conductivity 80-240μs/cm

Item	Main Component	Brand
System function	Brief	Industrial-grade equipment can run 24 hours a day without interruption, automatic alarm and shutdown when there is insufficient raw water, acid or alkali water full. Key indicators such as pH value are displayed in real time through online meters.
Electrical and Automation Control	Breaker	ABB
		AC contactor	ABB
		VFD	ABB
		PLC	Siemens
		Touch screen	Siemens
		Terminals	PHOENIX
		Cable	LAPP
		Level Switch	Taiwan Radar
Electrolysis device	Electrolyze	Titanium platinum alloy plate (Our Patent)
Electrolysis device		Electrolytic power supply	Customized military grade
Waterway valve	Stainless steel valve	304 Stainless steel(Shangdong Public company)
Waterway valve		UPVC pipes	Food grade，Fromosa Plastics(top company from Taiwan)
Online meter	Inlet conductivity	Create From China(Public Company)
Online meter		Outlet pH	Create From China(Public Company)
Dosing system	Dosing pump	SEKO From Italy
Dosing system		box	PE
Control cabinet	304 stainless steel	Aqua
Water treatment cabinet	304 stainless steel	Aqua

Certifications

Successful Project

Project in South Korea

108T/H

Project in China

one of the biggest water supplier

30T/H

Project in Indonesia

8T/H

Application

Food Beverage

There are a lot of pesticide residues in vegetables and fruits. The use of alkaline water can effectively remove these residues. At the same time, alkaline electrolyzed water is harmless to the food itself.

Food industrial

Marine product storage and preservation

Cleaning of Marine product processing equipment and utensils

Breeding environment and utensil disinfection

Livestock drinking water.

Slightly acidic electrolyzed water is pumped into the pipeline and directly used by livestock and poultry, which can effectively play a role in disinfection and sterilization.

Restaurants and Feeding Industry

Strongly electrolyzed water can kill all kinds of bacterial such as E.coil. Staphylococcus aureus, salmonella,vibrio parahaemolyticus and etc,

Medical instrument

you can sterilize many kinds of bacterial on the surface of medical tools and prevent infection from the tools

Restaurants / feeding facilities

It solves the hygiene problems in the slaughter house by sterilizing floor and facilities and deodorizing smells of blood and rotten meats

Alkaline water ionizer Machine

1/ PH 7-10 drinking Alkaline water

2/ 1000LPH smallest production

3/ To making drinking Alkaline water with safe technology, doesn't add any chemical to Adjust PH , only by ionizer

Hydrogen rich ionizer machine

1/ to make hydrogen water, Dual-core electrolysis

2/PH 7-10 Ajustment

3/OPR depends on customer

4/Hydrogen content normally 1.2-1.6ppm, but we can customize.

Strong Acid / alkaline machine

1. to make PH 12-14 Alkaline water

2. Function: Used to clean food, industrial, sterilize,agriculture ,medical etc.

Q1：Why Choose US

A1: We made the industrial type alkaline water ionizer machine.the quality is the top in ionizer industrial. We do not need more maintenance cost, cause our machine is very stable.

Q2: Why your price is higher than others ?

A2: At first pls check the appearance of our machine, we are industrial type not commercial or household, our machine stability, life time, technology, configuration of the machine are not in the same level.

Q3: You also mentioned that you are the industrial Type not Commercial type, what is that meaning ?

A3: commercial type equipment with lost cost, so it can be accepted by people in the market, like the air conditioner, it is necessary for each family, but we only used a quarter of a year ; Likes the air conditioner in the supermarket, it will be used 80% in a year. Alternate use of cooling and heating modes, so the parts in side required high level, the life time should be longer, the quality should better, and required higher stability, Cause market is a public place, it is very important for them, but if you used a household machine into commercial usage, it will be broken soon, and the efficient is lower.
