Bottled Automatic Sunflower Oil Plant / Oil Bottling Machine

Bottled Automatic Sunflower Oil Plant / Oil Bottling Machine

This type machine is suitable for filling viscous,inviscid and corrosive liquid.It's widely applied in plant oil,chemical liquid,and daily chemical industry.It adopts linear type filling,electromechanical&instrucmental intergration controlling.It's simple and rapid for changing the varieties with unique design and superior capability.It's appearance accords with the international machinery concept.

Germay SIEMENS PLC and touch screen control make it intelligentize protection function.Vacuum anti-dropping device ensures no leaking situation in production.Electrinic ajusting for volume system,frequency control and photoelectric detecting system(Germany TURCK brand) are applied in this machine.

Bottled Automatic Sunflower Oil Plant / Oil Bottling Machine

Containers and Specifications
Project Name:Automatic Piston / Flowmeter Filling Machine				Oil and Fat Products
Bottle Material	Bottle Shape	Filling Range	Filling Heads	Production Capacity
PET / PP / PE / Glass / Metal	Round / Square / Unique Shape	200ml-6000ml	4-16	700-4000bph
Filling Valve	Each filling valve is controled by servo motor ,realizing segmented high-and low-speed control ; vacuum resorption devices without leakage.
Cap closing method	applicability for both crowning and capping, mechanical instant sealing or servocontrolled sealing
Bottle components	rapid replacement without tools, such as star wheels for bottle infeed and outfeed, and bottleneck clamps
Filling precision	limit deviation: ±2-3g standard deviation: 1.5
User Ambient Conditions		Temperature:10~40℃;Humidity:No dew
User Electrical Supply Specification		Voltage:380V±5%, 3phase; Frequency:50HZ±1%

Rotary Oil Filling Sealing Machine

This filling machine is a high-tech filling equipment controlled by microcomputer PLC programmable,equip with photo electricity transduction and pneumatic action. This machine is suitable for filling viscous and corrosive liquid,it is widely applied in plant oil,chemical liquid,and daily chemical industry.

MODEL	GY12-4	GY18-6	GY24-8	GY32-10
Capacity 500ml	3000	5000	7000	10000
Bottle Applicant	150-340mm
Power	2.2	3.84	3.84	5.6
Overall Size	200016702350	207019702350	246521702350	300025702350
Total Weight	2500kg	3000kg	4000kg	5000kg
Suitable Cap	Diameter 50-110mm
Filling Pressure	0.2-0.3Mpa
Filling Temperature	Room Temperature
