Automatic Bottle Filling System for Water Production

Automatic envasadora de botellas de agua / llenadora de agua llave en mano

1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.

 envasadora de botellas de agua  - Technical Dates :

Flow Chart :

A)Bottle production line :PET Resin --Injection moulding machine -Botlte blowing machine --PET bottle

Blowing machine we can supply 2 cavity/4 cavity/6 cavity/8 cavity automatic servo type, if customer budget is limited, you can choose 2 cavity/4 cavity semi automatic one.

B)Water treatment system : Raw water--Pump--Silica sand filter--Carbon filter--Water softner--Reverse Osmosis -UV sterilizer-Ozone generator--Finished water tank

We supply 1T/H-20T/H mineral water / pure water treatment system, the membrane we adopt DOW/HYDRANAUTICS (America Brand) get good taste out water

C) Water Filling Labeling Packing System : 3 in1 water filling machine -- light checker -- bottle dryer -- automatic pvc shrink labeling machine/sticker labeling machine -- ink  jet printer/ laser printer -- PE film shrink wrapping machine/ carton box packing machine

3 in 1 water filling machine includes :

empty bottle feeding air conveyor

washing filling capping

automatic cap sorting

filled bottle out conveyor

single electric cabinet control

online cap sterilizer option

oil-gas separator option

automatic lubricant oil loading system option

Labeling machine includes : pvc shrink labeling machine / sticker labeling machine / bopp hot glue labeling machine

Packing machine includes : pe film shrink packing machine / carton box packing machine (4*6/3*4/2*3)
