AQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling Line

Description of AQUA Fully Automatic Small Bottled Water Factory /  Small Scale Mineral Water Filling Line

1. filling production: 1000-35000 bottles per hour.

2. bottle range 300-2000ml, 5-10L. 15-20L, will be different machine.

3. we supply complete line from

  a.bottle blowing machine

( 99% filling machine supplier got from other factory, but we make it by ourselves, it is our advantage)

  b.water purification system,

  c.3 in1 filling machine,

  d.labeling machine,

  e.printer,

  f. shrink wrapping machine /  carton packing,

  g. palletizer,

  some of them are also purchasing from other supplier, we will be honeset to customers,





Technician parametesr of AQUA Fully Automatic Small Bottled Water Factory /  Small Scale Mineral Water Filling Line

Model DCGF 8-8-3 DCGF 18-18-6 DCGF24-24-8 DCGF32-32-10 DCGF 40-40-12 DCGF 50-50-15
Rinsing nozzles 8 18 24 32 40 50
Filling nozzles 8 18 24 32 40 50
Capping nozzles 3 6 8 10 12 15
Output(@500ml) 1000BPH 3000BPH 5000BPH 8000BPH 12000BPH 15000BPH
Applicable bottle size Diameter=50~108mm, H=170~340mm, 330~2250ml
Pressure of air source 0.7MPa 0.7MPa 0.7MPa 0.7MPa 0.7MPa 0.7MPa
Air Consumption 0.25M3/min 0.8 0.8 0.8 0.8 1
Pressure of spraying water 0.2-0.25MPa
Consumption of rinsing water 1T/H 1.2T/H 1.2T/H 2T/H 2.2T/H 2.5T/H
Pressure of filling 0.2-0.3MPa
Power consumption 2.5kw 3.5kw 4kw 5.5kw 6.5kw 8kw
Machine body SS304
Machine size(L*W*H,mm) 2100*1800*2400 2300*2200*2400 3000*2200*2800 4000*2600*2800 4700*2900*2800

5100*4800*3000
Machine weight(kg) 2500 3000 4000 5000 6000 7500
PLC Japan Mitsubishi



AQUA Fully Automatic Small Bottled Water Factory /  Small Scale Mineral Water Filling Line



This line is from the same customer in Armenia.

Water purificaton system : Ro water treatment

AQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling Line



Rinser filler capper 3 in 1 filling machine ( 6000-8000 bottles @ 500ml PET bottle)

 AQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling Line



Details of the Water Filling Machine



 AQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling LineAQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling LineAQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling LineAQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling LineAQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling Line



Packing line

Sleeve labeling machine

AQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling Line





Pe Film Packing Machine

AQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling LineAQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling LineAQUA Fully Automatic Small Bottled Water Factory / Small Scale Mineral Water Filling Line
