linea de produccion de botellones de agua

Product Description linea de produccion de botellones de agua
(1) Suspending bottle-neck clamping design make the bottle stable during the high-speed moving conditions. By changing a few parts, it can meet the need of production of different types of bottles easily.
(2) The new generation of stainless steel grab is adopted and the grabs have no contact with the area above the bottle"s screw thread. Nozzles in the grab can guarantee the complete wash of the interior of the bottle.

(3) The advanced gravity filling technology used in this machine makes the filling quick, steady and accurate.

(4) Magnetic torque is used for screw capping, and the power of screw capping can be adjusted steplessly. Capping is reliable and do no harm to the caps.

(5) Advanced technologies, such as human-machine interface touch-screen and PLC program control are adopted in this mineral water plant machine.

(6) All parts that have direct contact with the water are made of high quality stainless steel. The critical electrical components are from famous international companies, such as Mitsubishi, Omron to name a few.

SPECIFICATIONS
MODEL	CAPACITY	POWER	BOTTLE SIZE
CGFA12-12-5	4000BPH 500ML	2.5KW	300ML-2000ML
CGFA18-18-6	6000BPH 500ML	3KW	300ML-2000ML
CGFA24-24-8	8000BPH 500ML	4KW	300ML-2000ML

This machine is comprised of rinsing, filling and capping system. Rinsing: grip the bottle neck, rotate filling plate, inverse bottle; internal rinsing and external spraying make bottles be cleaned completely. Filling: gravity filling with holding bottle neck; the special backflow type of the filling valve can avoid leakage after filling and also control liquid level accurately. Capping: magnetic torque bottle holding type can minimize the cap damage rate and make the capping performance the best.
Detailed Images Name: Water Treatment System
Brand: AQUA
Material: SUS304 Food Grade
The system is used for treatment the raw water to be cleaning and drinking, commonly choose Hollow fiber filter or Reverse Osmosis System . After treatment,it will be for filling machines to fill into pet bottles.
Name: Bottle Washer Filler Capper Machine
Brand: AQUA
Capacity: 2000-20000BPH
The machine is used for fill water into pet bottles by washer filler capper 3 steps. It with cap loader which can transfer cap to seal bottle automaticly. And with Famous brand PLC and touch screen to control the filling speed. The material which touch water will be all SUS304
Name: Automatic PVC Shrink Labeling Machine
Brand: AQUA
Capacity: 9000-20000BPH
The machine will connect with filling machine,after filled bottle water,the conveyor will take bottles to this machine for  shrink pvc labels on bottles by steam generator. The machine includes shrink tunnel/steam generator/shrink labeling machine.
Name: Automatic PE Film Shrink Wrapping Machine
Brand: AQUA
Capacity: 8-20pcaker/min
The machine is used for packing filled bottles to be 4*6/3*4/2*3 Packer by PE Film. It includes wrapping table/shrink oven/control table. Our Company Workshop 1 : Bottled Water Filling And Packing Machines
Workshop 2 : 3-5 Gallon Water Filling Packing Machine
Customer Visiting Welcome Zhangjiagang Aqua Machinery Co.,LtdZhangjiagang Aqua Machinery Co., Ltd is specialized in bottled beverage production and packing equipment . We are one of the companies engaged in manufacturing liquid filling and packing equipment in China. We can provide turn-key services for customers, from plant layout, equipment manufacture and production line setup to operator training.
Aqua-Machinery main business are : Bottled Liquid Filling Machine(Water/Juice/Carbonated Drinks/Edible Oil/Milk/Alcohol Drinks). Barrel Water Filling Equipment(3-5 Gallon).Shrink Labeling Machine/Stick Labeling Machine/Hot Glue BOPP Labeling Machine.PE Film Shrink Wrapping Machine. Bottle Blow Moulding Machine/ Preform Cap Injection Machine/ Water Treatment System Etc Filling And Packing Production Line.

Now our machines are exported to overseas with good feedback, we will do our best reach customer's requirement. Customer Satisfaction is our Service Purpose.
Our Service Pre-Sales Service * Inquiry and consulting support.  * Sample testing support.  * View our Factory. After-Sales Service
* Training how to instal the machine, training how to use the machine.  * Engineers available to service machinery overseas. Packing & Delivery

Packaging
Size	20GP/40GP/40HQ by order
Weight	BY ORDER
Packaging Details	The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
