Stable Quality Small Water Bottle Manufacturing Plant Making Plant / Bottle Blowing Machine

Stable Quality Small Water Bottle Manufacturing Plant Making Plant / Bottle Blowing Machine

1. It is used to make PET bottles

2. we have different capacity blowing machine from 600-14000pcs.h, tell me your requirement, so we can give the solution.

3. For 0.1-20L bottle size .

4. water bottle, carbonated bottle can use the same machine, juice machine will be different. so customers should be clear.

Recently we shipped a 7000bph bottle blowing machine, here share some pictures for reference

Stable Quality Small Water Bottle Manufacturing Plant Making Plant / Bottle Blowing Machine

Main electic Component of our Bottle Blowing Machine

Electrical components

PLC

Taiwan Delta

Cylinders

clamping cylinder

SMC

touch screen

Taiwan Delta

stretching cylinder

SMC

relay

Schneider

bottle-takeout flipping cylinder

FEST0

circuit breaker

Schneider

first-stage slide cylinder

SMC

air switch

Schneider

second-stage slide cylinder

SMC

start button

Schneider

heating cylinder

SMC

two-position switch

Schneider

Preform-separating cylinder

SMC

scram button

Schneider

Manipulator cylinder

SMC

power supply

Schneider

Bottle die cylinder

SMC

proximity switch

Schneider

Valves

high pressure blowing valve

PARKER

photoelectric switch

Schneider

high pressure exhaust valve

PARKER

Air Filtration

low pressure oil-water separator

FEST0

3 in 1

high pressure one-way valve

FEST0

low pressurepress-regulating valve

low pressure muffler

SMC

low pressure lubricator

high pressure muffler

ALWITCO

Technicial Parameters of Bottle Making Machine

Constituent Part	Item	Technical Parameters
Product Specifications	Max Volume	1800ml
	Max.container diameter	Φ105
	Max Container Mouth diameter	Φ18mm - 38mm
	Max.container diameter	330mm
	Max. Preform height embryonic tube	180mm
	Clamping stroke	120mm
	Base mould stroke	50mm
	Bottle Spacing	114.3mm
	Standard thickness of mold	220mm
	Capacity	4000(500ml)
	Mould	4
Heating Part	Heating Unit	5
	Heating lamp laye	9
	Number of tubules	80
Machine Power	Voltage	220/380V
	Frequency	50/60Hz
	Power	35kw/h
	Installed power	75kw
Air Source	High pressure compressed air pressure	25~30bar
Air Source	High pressure compressed air consumption	3.0m3/min
Water chiller	Pressure	3bar
Water chiller	Chilled water yield	5m3/h
Weight	Main machine \ Heating machine \ electric control box	3.5T
Machine Size	Machine (L×W×H)	4500mm×2200mm×2300mm
Machine Size	Preform-loader(L×W×H)	2000mmx1400mm×2500mm
