Chocolate Mass Delivery Pump

This pump is the most ideal food manufacturers chocolate pulp conveying pump, can be used for fine grinding cylinder, chocolate, insulation, thermal control cylinder cylinder transmission between chocolate paste, also can be used in the pharmaceutical, oil and other industries preferred delivery pump.     When the pump according to the principle of gear extrusion, using hot water jacketed heat preservation function, insulation for conveying fluid can implement all-weather work.

When the pump by the pump body, cycloid reducer, motor of three parts, compact structure and reasonable, stable and reliable work, fault repair rate is low, can be customized in accordance with the requirements of production sites, any adjustment about import and export, greatly facilitate the user's installation.     Technical parameters

Model	MJB-100	MJB-150
power of the motor	2.2KW/380V	2.2KW/380V
converying rate	32-250 L/H	32-400 L/H
converying lift	12m	12m
engler viscosity of syrup	48°E36	48°E36
production weight	70kg	120kg
dimensions	850*300*250mm	950*350*640mm
