Chocolate Moulding Line

        Product Description      MSJZ Automatic Chocolate Moulding Line

    This  moulding machine can automatically warm-up the mould, depositing and vibrating, it is suitable for depositing a lot of geometric chocolate, two colors, center filling, chocolate with granular nuts, it is adaptable and convenient operation.   BASIC SPECIFICATION:

PLC controlled stepper motor	125-5000r/min
Capacity	12-20 moulds/min
Working pressure	0.6Mpa-0.8Mpa
Vibration frequency	2940R/MIN, 220V 0.30KW
Temperature for warm-up mould	35-45C
Water tank heating-up temperature	55-60C
Rotation driving cylinder of depositing	φ63*50 2pcs
Driving cylinder of depositing plunger	φ100*100 2pcs
Driving cylinder of stripping	φ50*50 total 1pc
Plastic mould dimension	275*175*25mm
Installed capacity	6KW
Main machine	0.75KW-110BYG350B
Mould warm-up power	0.4KW*4=1.6KW
Water tank heater	3KW -380V
Machine dimension	4200*520*1450MM
Machine weight	420kg

        In this automatic chocolate moulding equipment can produce following types of chocolate:
pure chocolate
center filling chocolate
two color chocolate
three color chocolate
Cereal bar chocolate
Hollow chocolate
Chips chocolate
nuts mixed chocolate (nuts feeder unit required)     Chocolate moulding line           Customer visit Maike chocolate machine factory:         Maike chocolate machinery factory exhibition:
