MJLJ chocolate refine conche

Specifications 1.chocolate refine conche

2.temperature controlling system

3.self-contained cyclic filtering system

  Product Description    MJLJ Chocolate Refine Conche   1.This chocolate refine conche is used to get higher chocolate material after conching machine, chocolate material transfer via syrup pump and flows into this chocolate refine conche through sieve filter vibration. Chocolate material inside the drum makes the cyclic sieve filter refining under the function of mixer and syrup introducing pump.   2.Automatic temperature control can meet the technological requirements, this equipment is necessary for high quality chocolate.   3.Equipe with temperature controlling system, temperature control can be operated sensitively, accurately and visually; and it is easy to observe.   4. Equipe with self-contained cyclic filtering system. Circulating pump is suitable to be used for chocolate production technology; and the drum, circulating pipe and pump are provided with interlayer sleeve temperature holding system.   5.The chocolate material is filtered through two 40-mesh and 60-mesh vibrating sieves, which are easy to be dismantled and cleaned.   BASIC SPECIFICATION:

Model	MJLJ-1	MJLJ-2
Equipped power	8kw/380V	9. 8kw/380V
Main shaft rotation speed	14r/min	14r/min
Weight	1520kg	2450kg
Dimension	1200*1200*1200 mm	1400*1400*2800mm
Effective volume	1000L	2000L

  MQM-1000 Chocolate Milling Machine 1.This chocolate milling machine is the basic equipment to mill chocolate material, it also can be used to melt oil-bearing material, fluidness and some chemical raw material.
2.Chocolate raw material is melted via steel ball, milling fineness can be 20-25um.
BASIC SPECIFICATION:

effective volume	1000L
milling time	10-16H
drive power	14.5kw
dimension	2800*1600*2500mm
weight	4500kg

machine picture: Feel free to contact us
