Machine producing chocoalte beans

Specifications 1.Machine producing chocoalte beans

2.producing capacity:100~300kgs/h

3.PLC operation

  Chocolate bean:     MQD Chocolate Bean Making Machine       1.This chocolate bean making machine specializes in making colorful chocolate core material, chocolate bean, etc.       2.It can make the relative forming moulds according to the chocolate shapes, such as spherical shape, button shape, olive shape, cashew shape, triangle shape, etc.       3.The chocolate syrup is feed from the thermal tank thought the pump to the mould, the mould is working under the refrigeration situation, the lowest temperature can be regulated to -28°C–30°C, it makes the liquid syrup in the mould become solid in a moment, and then transferred to cooler of 5°C--8°C thought conveyor for further definite form.        4.The finalized shape enters the roller screen barrel for remove the burr of the core, and automatically discharged.       5.The part that moulding contacting with the foods uses special products, which behaves in conformity with Food Sanitation GMP.       6.The moulding procedure is finished in a seal cavity, conformity with Food Sanitation GMP, less influence by the ambient temperature & humidity, with reducing the production cost, easy to change the moulds, reducing the time to stop machine, and improving the machine utilization ratio.       7.Having real time monitored control system and guarantee the products quality, improving the production rate.       8. Working area conditions requirements:   1)Cooling and heating fan pipe cooling air:5-12  hot air:40-50drying   2)Air purified system installed   3)Room temperature: 18~22, humidity: 45%-55%;   4)Drying room:150M2       BASIC SPECIFICATION:

Producing capacity	100-300kg/h
Total power	45kw
Dimension	11650 x1200 x1800MM

        MPG Chocolate bean polishing Pot   1.This chocolate bean making machine is an ideal equipment for sugar coating making, it is applicable for pharmaceutical, foodstuff, chemical industries and so on. It is popular used in food industry for making sugarcoated pills or coating covering.   2.Professional and convenient coating machine. It can be used to polish chocolates of various shapes such as cylinders, oblatenesses, ellipsoids, melon seeds and balls to make their surfaces lustrous and colored and the chocolates will have a nice-looking shape after been polished.   3.Diameter of pan:400-1250mm just as buyer's requirement.   4.This chocolate coating machine polishing function can also cause the aluminum foils tightly and flatly stick to the color-foiled chocolates of different cylindrical shapes to make their geometrical shapes clear.   BASIC SPECIFICATION:

Model	MPG-800	MPG-1000	MPG-1250
Dia. of Pan (mm)	800	1000	1250
Rotary Speed of Pan(r/min)	36	32	32
Power of Fan (kw)	0.12	0.12	0.12
Power of Heat (kw)	2	2	2
Capacity(kg/time)	36-50	45-70	90-125
Motor (kw)	1.1	1.1	1.1
Size  (mm)	800*1000*1520	1000*1100*1620	1300*1100*1600
Weight  (kg)	260	270	360

Feel free to contact us   Customer visit Exhibition Machine producing chocoalte beans flow chat
