Aluminium Honeycomb marine board

Aluminium Honeycomb marine board:     Paper honeycomb core is made of recyclable paper through specially developed production equipments.  The hexagonal shape of honeycomb core is similar to natural honeycomb constructed by bees. Generally speaking, the strength of Honeycomb Core depends on the cell size and weight of the core. The smaller the cell size is, the smaller the height is, the better the material is, the higher the strength will be. Customers could order special widths as well. In accordance with customer's requirement, honeycomb core can be treated with waterproof or fire resistance.

Aluminum alloy	A1101,A3003,A5052
Foil thickness	0.04,0.05,0.06,0.07,0.08,0.1,0.2
Core's cell size	1-30mmm
Max width of aluminum foil	1600mm

  Flatwise Compressive Strength&Shear Strength

Thickness of coil / Side length(mm)	Density (kg/m2)	Mechanical Features under Room Temperature(Mpa)
		Flatwise Compressive Strength	Vertical Shear Strength	Flatwise Shear Strength
0.03/5	27	0.53	0.44	0.24
0.04/5	31	0.66	0.53	0.30
0.03/4	33	0.73	0.58	0.33
0.04/4	39	0.98	0.75	0.43
0.05/5	41	1.07	0.80	0.47
0.03/3	44	1.18	0.89	0.52
0.06/5	49	1.43	1.03	0.60
0.04/3	52	1.60	1.15	0.67
0.05/4	53	1.65	1.18	0.69
0.06/4	61	2.07	1.48	0.86
0.03/2	66	2.39	1.70	1.00
0.08/5	67	2.45	1.74	1.02
0.05/3	68	2.50	1.78	1.04
0.04/2	77	3.10	2.18	1.25

  Normal Aluminum Core

Side length (mm)	4	5	6	7.5	10	12	15	20	30
Cell size (inch)	1/4	1/3	3/8	1/2	3/4	4/5	1	1	2
Expand maxi dimension (long x width) (mm)	1800 x 3100	1800 x 4000	1800 x 4600	1800 x 6000	1800 x 7500	1800 x 9000	1800 x 12000	1800 x 15000	1800 x 20000
Thickness of aluminum coil (mm)	0.04 – 0.07	0.04 – 0.07	0.04 – 0.07	0.04 – 0.07	0.04 – 0.07	0.04 – 0.07	0.04 – 0.07	0.04 – 0.07	0.04 – 0.08

      Use temperatures up to 350° High thermal conductivity Flame resistant Excellent moisture and corrosion resistance Fungi resistant High strength-to-weight ratio Good Flatness Excellent bonding strength Corrosion resistant        Packaging industry: Paper pallet, Paper honeycomb panel, Paper honeycomb carton etc. Furniture manufacturing: Door, Wall units, Office table, Screen etc Building decoration industry: Clean room, Ship, Decorative sheet, Partition wall, Exhibitions stand, Open-style office, Processing door etc.           marine board , curved honeycomb panel , marine panel  marine board , curved honeycomb panel , marine panel marine board , curved honeycomb panel , marine panel marine board , curved honeycomb panel , marine panel
