SRL300/600L pvc hot and cool mixer / hot cold mixer / plastic mixer

Product Description   SRL 300/600L pvc hot and cool mixer / hot cold mixer / plastic mixer

item	name	Specification
		Hot mixer	cold mixer
1	The total volume	300L	600L
2	Effective volume	210L	400L
3	Impeller number	3	1
4	Impeller speed	950 r/min	90 r/min
5	Heating methods	Friction
6	Cooling methods		Cooling water
7	Cooling water		> 0.1Mpa
8	Cooling water temperature		0-15 ℃
9	Mixing time	8-12 min/pot	10-12 min/pot
10	Power	55kw	11kw
11	The material of hot and cooling mixer body, bottom	SUS304 (6mm)
12	Inverter	ABB (ACS510-01-125A-4)
13	Pot cover, three links	Cast aluminum
14	Pot cover opening method	Opening by pneumatic device. Rotating by manual
15	Hot mixer paddle structure and material	Three overlapped, stainless steel precision casting, and by the static and dynamic balance test
16	Keep temperature way for hot mixer	Using heat conduction oil and insulation cotton
17	Cold mixing paddle structure and material	Rotary type, stainless steel precision casting, and by the static and dynamic balance test
18	Discharging part material	Aluminium alloy with moving plunger (pneumatic control)
19	Discharging method	manual or temperature self-control
20	Electric control box	One set
21	Temperature controller	Japan OMRON
22	Electrical components	Siemens
23	Total weight	About 3800kg
24	Packing volume	About 14m3

1. It is used for the process of mixing, drying in the industries of plastic, rubber, chemical and the place of lab as well.  2. The upper set is for hotting, and the lower one is for cooling  3. Five parts: two containers, transmission agent, pneumatic components, cooling system and base structure
4. Its lid adopt double sealed.
5. Hot mixer is with the heating ways of self-friction. 6. Using heat conduction oil and insulation cotton to keep temperature in hot mixer. 7. With discharging ways of temperature automatic control and manual control.
8. The container:  A. The interior is made of stainless steel with polished finish;  B. The cover adopts aluminium alloy castings with inlet orifice and air exit hole, we also can produce it as your requirements;  C. The discharge hole is made of aluminium alloy; the valve is controlled in the force of pneumatic;  D. Paddles are entirely made of stainless steel and through dynamic and static balance test.  E. Temperature measuring equipment (TME) in the interior wall of the container;  9. The electric control system adopts the components of famous brand.  10. It can also use ABB inverter.     Packaging & Shipping 1) Cover with plastic film, 2) Then be placed in wooden case and wooden pallet. 3) Next be fixed in one 20 feet container. 4)20 feet container transport by sea or train..    Our Services 1) We recommend of machine and auxiliary equipments and relevant budgeting, human resources allocation and budgeting. 2) We would like to answer any inquiry within 48 hours and it will be solved as soon as possible. 3) The buyer can send the worker to our company for training. 4) The Seller supplies the complete technical support documents and the relative drawings of the electric components written in Chinese and English. 5) Our engineer can be to the Buyer’s company for installation and testing the lines. Company Information Our factory is near Shanghai city. We are a gold supplier of Alibaba for 6 years. And have passed ISO9001:2008, SGS. In last few years we have exported to Russia, Belarus, Ukraine, Belarus, South Africa, Nigeria, Morocco, Zambia, Saudi Arabia, Egypt, Jordan, Lebanon, Pakistan, Bangladesh, Uzbekistan, Braril, Argentina, Mexico, Uruguay, etc. For some main parts, we usually use Siemens/ABB/Omron/ Schneider brands in order to ensure better quality.
