universal water heater manufacturer ,solar water pump system

Specifications 1,Germany improted blue titanium absorbers

2, Laser welding for copper and absorber

3, 25 years lifetimes,SRCC Solar Keymark

       Compact solar water heater Introduction              Advantages:          (1)European and American design style        (2)The natural circulation system of , free maintenance;         (3)Auxiliary electrical heating, with temperature controller and manual           overheat protector;           (4) The inner tank use food-grade 304 stainless steel or enamel materials,            corrosion resistance, long service life;         (5)Using high efficient flat plate collector;         (6) System uses indirect heat, suitable for various climate installation.               Specifications:

Category		P-JF2-150/1.8 0/0.70-ZFF-2. 4-01
Enamel water tank	Circulation way	Pressure-bearing  indirect cycle
	Water tank	150L
	Size	Φ555*1200mm
	Shell material	Porcelain white choi steel
	Jacketed heat exchanger area(m2)	1.2
	Max working pressure	0.6Mpa
	Jacketed max working pressure	0.3Mpa
	Auxiliary electrical heating	2.0kw
Solar collector	Model	FP-GV2.0
	Size( L x W x T )	2000 x 1000 x 80mm
	Total area	2m2x 1pcs
	Absorb plate material	Whole plate aluminum
	Heat absorption coating	Imported blue titanium/Black chromium plating
	Header tubes	red copper/ Φ22*0.6
	Row tubes	red copper / Φ8*0.6
	number of row tubes	8 pieces
	Welding	Whole plate laser welding
	Cover plate	Low iron cloth tempered glass
	Frame material	Aluminum
	Insulation	Wave fiber cotton
	Connector size	DN15 outside

  Our company has two more kinds compact solar water heater system which are 200L 300L its bracket are aluminium alloy or wearthering steel  ,its circulation tubes material are  304 stainless steel bellows (Φ 22 mm)/red copper tube (Φ19 mm)  .....                                                         Our company specializes in split and compact solar water heater system for five years,    products passed certifications of SRCC,Solar Keymark,CE, CCC and so on.besides we have    owned national patent for S-shaped solar collectors ,company has 100000 pieces annual    production capacity for both domestic and foreign market.we have done many solar system    project in domestic market.    our split system is from 150L-500L ,compact system is 150L 200L 300L, both are pressurized    system !our flat plate solar collector has three size 2000x1000x80mm,     2050x1050x95mm,2015x1015x76mm,with imported blue titanium absorber,more than 92%    absorptivity .more solar water heater or flat plate solar collector details pls feel free to send inquiry !               Exceed  Customer Needs                                                  Create Customer Value  !  !  !
