Split Pressured Solar Water Heater with Flat Plate Solar Collector and 150 to 500L Solar Water Tank

Split Pressured Solar Water Heater with Flat Plate Solar Collector and 150 to   500L Solar Water Tank   Model Number:HSB-95-300L pressured system Quality Assurance--Solar Collector Test   * Internal pressure for absorber
* High temperature resistance
* Exposure test
* External thermal shock
* Internal thermal shock
* Rain penetration
* Mechanical load test
* Thermal performance
* Freeze resistance test   * Ice ball impact test                                                            How to produce the collector ?  In-process
-Laser welder between absorber and copper tubing
-Process test with digital pressure meter at 1.2Mpa 5 minutes
-Automatic S type bending machine
-Automatic frame cutter
-Automatic frame assembly machine
-Automatic copper drilling machine
-Automatic plate leveling machine   System Special Features: Blue-titanium coating Flat and sloped roofs or freestanding Vertical or horizontal installation Compatible with any DHW heating system Connect up to 12 collectors in series Commercial or residential systems Black chrome or blue titanium absorber sheet coating Optical efficiency: 96.3% Heat loss coefficient: 3.95 Optimized collection of solar energy with highly efficient sol-titanium coating Rugged, using impact-resistant solar glass, copper, aluminum and non-degrading thermal insulation Maximum system performance and reliability With full range of solar system components designed to integrate seamlessly Fast installation With flexible connection pipes and quick-connect fittings Prefabricated collector mounting hardware ensures easy connection to roofs Suitable for many applications Best suited for DHW or pool heating System Main Configurations   1.Controlled by computer all the time   2.Imported blue titanium whole board solar collector from Germany   3.Pump station:SP116   4.Brand expansion case   5.Enamel/stainless water tank,depends on the buyer   Water Tank Specifications:

Tank Capacity S-S/Enamel	Solar Collector FP-GV2.0	Electrical backup	person available
100L	2m²	1.5kw	2-3
200L	2m² or 4m²	1.5kw	3-4
300L	4m²	2.5KW	5-6
500L	8 m²	2.5KW	8-10

  System Design Strength   ♦ 1.Collectors installed outdoor, safe and artistic.    ♦ 2.Water tank wall-hanged,making full use of Balcony Space   ♦ 3.Various installing ways,extensive applications   Certifications: Solar-keymark,SRCC,CE About Sinoyin Solares   Sinoyin Solares is a famous solar factory located in Suzhou Industrial Park,it mainly specialize   in developping and producing high quality flat plate  solor collector and solar water heating   system for more than 6 years.   Why choose Sinoyin Solares?   1.S-type tube flat plate solar collector,have gotten the line patent in China.   no any welding on the  tube,no any leakage.   2.Whole plate laser welding,to minimize the damage to absorption layer.   3.The instant heat efficiency of the collector can up to 81.1%,much higher   than the 72% line standard,very rare in China.   4.The Solar Poducts has been selected into the official web of China government,it can be   verified on the internet.   How to contact us ?   Victoria   Suzhou Sinoyin Solares Co.,Ltd   Web:www.sinoyin.com   Tel:86-0512-88876960/18915433725   Fax:86-0512-88876964   Products Showing Room   Sinoyin Solares in the Fair
