Winter solar heat pipe solar collector/High-end solar heat pipe solar collector for heating room

Winter solar heat pipe solar collector High-end solar heat pipe solar collector for heating room Specifications Dimension LxWxH (mm): 2050*1050*95mm Gross Area (m2 ):            2.15 Absorber Area (m2 ):       1.963 Number of covers:           1 Cover material:   Low iron, tempered glass Cover Thickness(mm):     3.2mm Cover Transmission:      >91.7% Weight:                          38kg Absorber Material:                  Aluminium board Surface Treatment:  Sputtering (Germany imported Blue titanium absorber ) Absorptivity:             95±2% Emissivity:               5±2% Construction Type:  Grid type Header Material:      Copper TP2 Header tuber size:   22mm* 0.8mm Riser Material:         Copper TP2/CA1220 Riser tuber size:      8mm*0.75mm Work Pressure:       0.75Mpa Test pressure:        1.2Mpa,keeps 5 minutes Whole collector

Max power G=1000W/  m² per collector	1.52kw
Thermal effiency	0.795
heat loss coefficient a1*	2.889 W/m².K
heat loss coefficient a2*	0.026W/m².K
Maximum stagnation temperature for ambient conditions of 1000W/m2 and 30°C	190.6°C

Thermal Insulation Insulation Material :Fiberglass Insulation Thickness :50mm Density: 48kg/cube for FP-GV2.15.00-A and FP-GV2.05-01-A , 36kg/cube for FP-GV2.0 Casing Frame :               Aluminium alloy Frame Colour :    silver or black Back Plate :        Aluminium plate Sealing Gasket : EPDM

Approved by Solar-keymark, SRCC, CE,ISO9001,CCC,etc.

REMARK: Full plate absorber, laser welding between absorbor and copper tube . Mechanical load, freeze resistace, rain penetration, exposure, hail impact, external and internal etc.tested Germany imported highly selective blue titanium coating. Good quality,high performance, excellent service
