pure sine wave 220 volt single phase inverter pure 24v 1500w
- Delivery Time:
- 14 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Jiangsu, China (Mainland) |
|---|
Models | SPR1500-112 | SPR1500-124 | SPR1500-148 | SPR1500-212 | SPR1500-224 | SPR1500-248 |
Output Power | 1500W | |||||
Surge Power | 4500W | |||||
DC Input Voltage | 12VDC | 24VDC | 48VDC | 12VDC | 24VDC | 48VDC |
Output Voltage | 100/110/120VAC±5% | 220/230/240VAC±3% | ||||
Output Frequency | 50/60Hz ±0.5% | |||||
Output Waveform | True sine wave(THD<5%) | |||||
Power Factor | 0.1~1 | |||||
Efficiency | 88% | 89% | 91% | 89% | 90% | 93% |
No Load Power | <10W(Power saving mode) | |||||
Transfer Time | <8 ms | |||||
AC Range | 184-253VAC (176-276VAC) /154-253VAC (150-276VAC) | |||||
AVR Output (optional) | 120VAC±10% | 230VAC±10% | ||||
DC Range | 10.0~15.5VDC,*2 for 24VDC, *4 for 48VDC | |||||
Charge Current | 50A | 25A | 20A | 45A | 25A | 15A |
Safety | UL458 | LVD(EN60950) | ||||
EMC | FCC Part15 ClassA | |||||
Operating Temp | -20~50℃ | |||||
Working Humidity | 20~90%RH | |||||
Storage Temp | -30~70℃ | |||||
Cooling | Automatically controlled cooling fan | |||||
Weight (kg) | 21 | |||||
Size (mm) | 19inch,2U Standard cabinet,482*400*132mm (L*W*H) | |||||
Application | Special Vechile,Yacht,airborne ,Communication field etc. | |||||
FAQ Q1. What kind of material of transformer? A. 100% pure copper transformer , NOT Copper-clad aluminun Q2. The standard of package? A. For the small capacity, it use carton, but for big capacity, we should use strong wooden case for protection. Q3.Would you accept to use our logo ? A.If you have good quantity,it absolute no problem to do OEM. Q4.Where is your market? A. Our products are popular in USA, Japan, Europe , Carmeroon, Sounth Africa ,Egypt ,Cambodia, Australia ,Canada ,Jamaica,Brazil and so on.Hope to cooperation with you ~ Q5.Application ? A.Viehicle,Yacht,Solar power system,Portable Equipments, Power tools,Home and Office appliances. Q6. What kind of certificate you have ? A. Our company already achieve ISO, CE ,ROHS,FCC,PSE UL(pending) .Also have patent for an invention Q7. What's the payment term? A. We accept TT,Paypal ,Western Union ,MoneyGram. Q8. Delivery time ? A. In normal it will take about 14-21 days after payment.
