72 cell poly panel 300w-345w

Get Latest Price

Payment Type:: T/T

Incoterm:: FOB

Min. Order:: 20 Piece/Pieces

Min. Order:: 20 Piece/Pieces

Delivery Time:: 10-15 Days

Transportation:: Ocean

Port:: SHANGHAI

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	CHINA
Productivity:	1GW/Year
Supply Ability:	10containers/Day
Payment Type:	T/T
Incoterm:	FOB
Certificate:	ISO9001
HS Code:	85414020
Transportation:	Ocean
Port:	SHANGHAI

Product Description

RS6S-P: TUV,PID,CE ,CQC certified high efficiency poly crystalline pv solar panel renewable energy,This Poly Solar Panel is 72 cells solar panel and it's solar power is high.

Rated power	300W	305W	310W	315W	320W	325W	330W	335W	340W	345W
Open circuit voltage	45.3V	45.51V	45.71V	45.81V	45.9V	46.1V	46.4V	46.6V	46.8V	46.9V
Short circuit current	8.66A	8.82A	8.87A	8.97A	9.08A	9.15A	9.23A	9.3A	9.38A	9.55A
Maximum power voltage	36.5V	36.5V	36.87V	37.06V	37.3V	37.5V	37.8V	38V	38.3V	38.5V
Maximum power current	8.22A	8.36A	8.50A	8.58A	8.61A	8.67A	8.74A	8.81A	8.88A	8.96A
Module efficiency	15.46%	15.71%	15.97%	16.23%	16.49%	16.76%	17.03%	17.25%	17.53%	17.70%
Solar cell	Poly-crystalline, 156.75*156.75mm, 5bus bars
Cell configuration	72cells (6*12)
Module size	195699240mm
Weight	22kgs
Front cover	3.2mm tempered glass
Frame	Anodized Aluminum Alloy
J-BOX	IP67
Cable	4mm2(IEC), 900mm
Connectors	MC4 or MC4 comparable
Maximum system voltage	1500V
Max series Fuse rating	15A
Limiting reverse current	15A

RS6SP

Production Flow

PRODUCTION

Certifications

Advantages

Sales network covers more than 80 countries with 1GW capacity each year, providing customers with instant after sales service and an efficient supply-chain.

In order to provide clients fast quality check and delivery time, so far we have built the warehouse in worldwide Deira-Dubai, Kampala-Uganda, Poland, Addis Ababa-Ethiopia, Dar es Salaam Tanzania and in Casablanca-Morocco, Bogota-Columbia and Santiago-Chile
