           the newest popular clear roof marquee wedding tent Pagoda Tent Series Pagoda Tent Series WT Pagoda Tent Series are adopted high strength argent oxidation Aluminum-Alloy (6061/T6) to produce the frame, It is antirust, light and easy for set-up. Roof Cover and Sidewall are made by the popular PVC fabric, frame retardant to DIN 75200, B1, M2. The seam of cover and sidewall is welded via high frequency welding technology. The seam is tight-sewed and free from water drops. WT’s Pagoda Tent can resist 80-100 Km/h wind. It has some advantages, such as small cubage, convenient to store, smartly to reset and easy for transportation, etc. WT can supply 3m , 4m, 5m, 6m, 7m, 8m and 10m square Pagoda Tent. And, we can also provide internal decorative accessories, such as lining, floor system, etc.   Product Description 1)Application of pagoda tent:  High class hexagon tent  for party (SS/HEX, Hexagon tent) can be widely used as the wedding tent, party   tent, exhibition tent,conference tent, different kinds of festivals tent, hajj tent, corporate events tent, sports   tent, & temporary, semi-permanent orpermanent building purpose etc.     Specification of  pagoda tent

Type	Span (m)		Side height (m)	Ridge height (m)	Peak Height (m)	Bay Distance (m)	Roof Pitch	Longest Component (m)	Wind Load (km/h)
SS6/2.6HEX/(HP)	6		2.6	3.7	5.2	3	20°	3.5	80
SS8/2.6HEX/(HP)	8		2.6	4.2	5.7	4	20°	4.3	80
SS9/2.6HEX/(HP)	9		2.6	4.4	5.9	4.5	20°	4.8	80
SS10/2.6HEX/(HP)	10		2.6	4.5	6.8	5	20°	5.4	80
MS10/2.6HEX/(HP)	10		3.3	5.2	7.5	5	20°		80
MS12/2.6HEX/(HP)	12		3.3	5.5	9.2	6	20°		80
Main frame Profile		SS Series:100x48x3mm(4-Channel)/MS Series:152x120x4mm(4-Channel)
Eave Connection		SS series: Hot-dip Galvanized Steel Insert / MS series:Hot-dip Galvanized Twin Steel Plate
Roof Fixing		Bar Tension
Frame Material		Hard Pressed Extruded Aluminum 6061/T6
Cover Material		Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,750-900g/sq.m

      2)Materials of pagoda tent:    2.1 pagoda tent  Frame:  1.extruded 4-groove aluminium hollow profiles. All aluminium components technically anodized.
2.High strength Aluminium Alloy 6061/T6. aircraft grade and oxygenation on the surface.
3.All steel parts are well hot-dip galvanized.
4.Modular character for diverse combination and expansion. Trouble-free transport, storage and    maintenance.
5.All system components are standard stocked parts for fast availability.   2.2 pagoda tent Fabric:
1.Textile covers made of polyester fabric, coated with PVC on both sides, weight approx. 850g/sqm.
2.Extremely durable and made of stable polyester material that is easy to clean and resistant to scratches.
3.Can be supplied with or without windows or can come with translucent or transparent sections.
4.Flame-retardant according to DIN 4102, fire class B1, M2.   2.3 pagoda tent Connections:   Hot-dip galvanized steel;   3)Life span of pagoda tent :   1.Life span of fabric(cover & sidewalls): 8-10years;   2.Life span of aluminum frame: 20-30years    4)Structure safety parameters:   1.Wind load: 100km/h (0.5kn/M2)   2.Snow load: 25kg/sq.m    5)Optional Accessories pagoda tent:
1.  This  hexagonal pagoda tent can decorate with roof lining and curtain, to make the tent more elegant and      beautiful.    2. This hexagonal pagoda tent can also equiped glass wall or ABS wall to make it a real building instead of     tent.    3. This  hexagonal pagoda tent can also decorate with wooden floor on ground to make it more classic.   4. All accessories we manufacturer: wooden floor, glass door, glass wall, glass window, ABS hard wall, steel        sandwich wall, ground anchors, anchor puller, weight plate, sidewalls with PVC-clear window, rain gutters,      decoration ceilings and inside curtain, ramp, transport rack.
