water pipe machine

Specifications water pipe machine

is mainly used in the

manufacture of plastic PP/PE/PPR

pipes

water pipe machine We can provide many kinds of plastic pipe extrusion line, such as PVC pipe production line, PE pipe production line, PPR production line and etc. Pipe production line features:

Human-machine interface, high degree of automation

Adopting special screw, good effect

Adopting compound spiral engine head, effectively deleting memory function of the material

Vacuum shaping, constant temperature control, deleting pipe stress

Adopting coextrusion engine head to improve the tube mark color line

Heavy extrusion volume, low temperature of melt, equal temperature of melt

Extensive material process range

1) Components: Extruding machine, vacuum spray shape fitting box, hauling off and cutting machine unit, stacking frame
2) Uses RKC from Japan to control the whole line, automatically operating
3) Improves production efficiency, saves labor force
4) Low trouble rate
5) Transformable arrangement, can be changed according to clients' needs for some arrangement

Line model	Extruder model	Pipe diameter mm	Line speed m/min	Total power/kw	Line length/m
CD-PPR63 Normal	SJ65/30 SJ25/25	16-63mm	1-12	69kw	23m
CD-PPR63 Efficiency	SJ65/33 SJ25/25	16-63mm	1-16	80kw	28m
CD-PPR160 Efficiency	SJ75/33 SJ25/25	75-160mm	1-8	180kw	45m

PE/PPR/PVC pipe production line specification as follow:

PE pipe production line:
Line model	Pipe diameter	Extruder	Max capacity (kg/h)	Total power (KW)	Line length (m)
CDPEG-32	Φ4-32	CDSJ45/30  CDSJ25/25	30-120	45	28
CDPEG-63	Φ20-63	CDSJ60/33  CDSJ25/25	120-220	100	36
CDPEG-110	Φ20-110	CDSJ65/33  CDSJ25/25	150-250	120	39
CDPEG-160	Φ63-160	CDSJ65/33  CDSJ25/25	120-270	150	43
CDPEG-250	Φ75-250	CDSJ75/33  CDSJ25/25	280-400	230	45
CDPEG-450	Φ110-450	CDSJ90/33  CDSJ25/25	450-600	350	65
CDPEG-630	Φ315-630	CDSJ120/33  CDSJ25/25	700-950	550	75
CDPEG-800	Φ400-800	CDSJ150/33  CDSJ30/28	800-1200	700	75
CDPEG-1200	Φ710-1200	CDSJ90/33*2  CDSJ30/28	1200-1500	1100	78
CDPEG-1600	Φ800-1600	CDSJ120/33*2  CDSJ30/28	1500-1800	1300	85



PPR pipe production line:
Production line	Extruder	Pipe diameter/mm	Line speed/M	Total capacity /kw	Total length /m
CD-PPR63 Normal	SJ65/30 SJ25/25	16-63mm	1-12	69kw	23m
CD-PPR63 High Effective	SJ65/33 SJ25/25	16-63mm	1-16	80kw	28m
CD-PPR160 High Effective	SJ75/33 SJ25/25	75-160mm	1-8	180kw	45m



PVC pipe production line:
Production line	Pipe diameter /mm	Extruder	Line speed /m	Total capacity /kw	Total length /m
PVC-40	16-40mm	SJSZ51	1-12m	56kw	21m
PVC-160	75-160mm	SJSZ65	1-8m	89kw	26m
PVC-250	110-250mm	SJSZ65	1-6m	95kw	32m
PVC-400	200-400mm	SJSZ80	1-6m	135kw	40m
PVC-630	315-630mm	SJSZ92	1-4m	255kw	52m
