500kg/h with CE ISO PE/PP Film Agglomerator

500kg/h with CE ISO PE/PP Film Agglomerator    This machine is auxiliary equipment for PP/PE film granulating and recycling. With the heat
originated from high friction, this machine can make the soft and loosen film
become solid, so they can easily enter the extruder to get large capacity.   Pictures:of 500kg/h  PE PP film agglomerator with CE |500kg/h                      PE PP film agglomerator with CE       1. Features:of PE PP film agglomerator with CE | PE PP film agglomerator with CE |
The plastic flakes densifier or agglomerator is used to granulate the thermal plastic films, PET fibres, whose thickness is less than 2 mm into small ganules & pellets directly. The soft PVC, LDPE, HDPE, PS, PP, foam PS, PET fibres and other thermoplastics are suitable for it.   And Motor is Simens.
2. Working Principle:of  500kg/h PE PP film agglomerator with CE|500kg/h PE PP film agglomerator with CE
When the waste plastic is supplied into the chamber of such machine, it will be cut into smaller chips due to the crushing function of the rotating knife and fixed knife. During the crushing processing, the material that soaked up lots heat from the frictional movement of material being crushing and the wall of container will be going to become semi-plasticizing state. The particles will stick with each other due to the function of plasticization. Before it sticks each other completely, the cold water pre-prepared is sprayed into the material being crushed. The water will be evaporated off quickly and the surface temperature of material being crushed drop down quickly also. So the material being crushed will become small particles or granules. It is easy to recognize the particles by different size and can be colored by using of color agent being putted into the container during the crushing processing. 3. Main Technicial Parameter:of 500kg/h PE PP film agglomerator with CE|500kg/h PE PP film agglomerator with CE

Model	GHZ-300	GHZ-450	GHZ-600
Volume	300L	450L	600L
Effective capacity	200L	350L	450L
Rotating blade Qty	2	2	2
Fixed blade Qty	6	8	8
Rotatting speed	950 rpm	950 rpm	950 rpm
Motor power	55kw/75kw	90kw	110kw
Output	250-300kg/h	350kg/h	500kg/h
