PC Polycarbonate Pipe Making Machine Line

Get Latest Price

Payment Type:: L/C, T/T, D/P, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Jiangsu Suzhou
Payment Type:	L/C, T/T, D/P, Western Union

Product Description

We can design the production line according to your special requirements. The following data is just for your reference.

1. Brief Introduction

Capacity: 340ton/ year, 2m/pc, from 2~12inch
   2inch polycarbonate pipe: 85ton/year, 1kg/pc, 85,000pcs
   4inch polycarbonate pipe: 85ton/year, 2kg/pc, 42,500pcs
   8inch polycarbonate pipe: 85ton/year, 4kg/pc, 21,250pcs
   12inch polycarbonate pipe: 85ton/year, 8kg/pc, 10,625pcs
   (It's only for your reference.)

2. Working time: 24 hours/day, 300 days/year

3. Workers (It is only for your reference.)
   Total workers: 2
1 worker for feeding material
   1 worker for finished product

4. Flow charts

4.1 Transparent polycarbonate pipe
4.1.1 Make polycarbonate into the dryer by feeding machine.
4.1.2 Dry for polycarbonate by dryer.
4.1.3 Extrude polycarbonate by single screw extruder and to mould, vacuum chamber, and haul-off machine, polycarbonate pipe will be output.
4.1.4 Make polycarbonate pipe into 2meters one piece by cutting machine and to the stacker.
4.1.5 Put the finished products into the cartoons.

4.2 Colorful polycarbonate pipe
4.2.1 Make polycarbonate and color granule mix by mixing machine.
4.2.2 Make polycarbonate into the dryer by feeding machine.
4.2.3 Dry for polycarbonate by dryer.
4.2.4 Extrude polycarbonate by single screw extruder and to mould, vacuum chamber, and haul-off machine, polycarbonate pipe will be output.
4.2.5 Make polycarbonate pipe into 2meters one piece by cutting machine and to the stacker.
4.2.6 Put the finished products into the cartoons.

5. Finished Product Polycarbonate Pipe
