SGS Cmt Shore Durometer
- Payment Type:
- L/C, T/T, D/P, Western Union
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Jiangsu Suzhou |
|---|---|
| Payment Type: | L/C, T/T, D/P, Western Union |
Product Description
Product Description
Application:
LX-D Shore Durometer is used to determine the hardness of high hardness material such as hard rubber, hard resin, organic glass, thermoplastic material, printing plate, etc. This machine conforms to ISO 7619, GB/T 531, etc.
Features:
Simple structure, easy to operate, light weight
Can be hand-held operation or installed on the test rack to operate
With max. Value locking function, automatically calculate the average value (for digital type)
With auto power-off function (for digital type)
Can connect to computer through RS232 communication cable (for digital type)
LX-D Shore Durometer is used to determine the hardness of high hardness material such as hard rubber, hard resin, organic glass, thermoplastic material, printing plate, etc. This machine conforms to ISO 7619, GB/T 531, etc.
Features:
Simple structure, easy to operate, light weight
Can be hand-held operation or installed on the test rack to operate
With max. Value locking function, automatically calculate the average value (for digital type)
With auto power-off function (for digital type)
Can connect to computer through RS232 communication cable (for digital type)
| Technical Specification | ||
| Model | LX-D | |
| Type | Dial type | Digital type |
| Range | 0~100HD | 0~100HA |
| Pressure needle travel | 2.5mm | 2.5mm |
| Size of needle head | SR0.1mm | SR0.1mm |
| Power supply | / | 3×1.55V button cell |
| Dimensions | 115×60×25mm | 173×56×42mm |
| Weight | 5kg | 5kg |
