Brittleness Temperature Tester for Lab Equipment

Get Latest Price

Payment Type:: L/C, T/T, D/P, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Jiangsu Suzhou
Payment Type:	L/C, T/T, D/P, Western Union

Product Description

Application:
Brittleness Temperature Tester is used to determine the temperature at which rubber, plastics and elastomers exhibit brittle failure under specified impact conditions. Brittleness temperature is that temperature, estimated statistically, at which 50% of the specimens wound probably fail. This machine conforms to ISO 974, ASTM D746, GB/T 1682, GB/T 5470, etc.
Features:
Three kinds of specimen clamps optional, one is for single specimen test, one is for A type multiple specimens test, the other is for B type multiple specimens test
Two kind of cooling method optional, one is semiconductor refrigeration, the other is compressor refrigeration

Technical Specification
Model	50
Temperature range	-60~0
Temperature fluctuation	<±0.5
Test speed	2m/s ±0.2m/s
Striking edge radius	R1.5±0.1mm for single specimen R1.6±0.1mm for multiple specimens
Clearance between striking arm and specimen clamp	11±0.5mm (for single rubber specimen) 8±0.3mm (for multiple rubber specimens) 3.6±0.1mm (for plastic test)
Volume of cooling tank	700ml
Power supply	AC220V, 50Hz, 1100w
Dimensions	720×700×1380mm
Weight	120kg
