Basic Info
Basic Info
Place of Origin: China
Payment Type: T/T, Western Union
Product Description
Product Description
ERUSUN-SA series blow moulding machine is the latest high output semi-automatic PET blow moulding machine. Comparing to the traditional machine design, thanks to new concept of automatic bottle discharging unit, the patented heating system and the preforms automatic loading design, The SA series blow molding machine requires less manpower and reducing the work intension for the operator. New SA series blow moulding machine holds the cavity of the blowing mold up to 6 cavities, the output reaches 1800BPH for 500ml water bottles. Compared to the output of normal manual blow moulding machine, this is an outstanding improvement in the PET Bottle blow molding industry.
M odel SA 4 SA6
Number of Cavities 4Cavity 6Cavity
Material PET/PC/PP/PE PET/PC/PP/PE
Clamping Force 180KN 300KN
Max Clamping Stroke 350mm 250mm
Bottom Moving Stroke 60mm 60mm
Max. Stretching Stroke 380mm 380mm
Theoretical Output 2000BPH 2800BPH
Max. area of mould base 620*420mm 750*420mm
Max. Mould Thickness 190mm 190mm
Space Between Tie Bars 550*340mm 670*340mm
Electrical system
Voltage Standard 380v/3PH/50Hz or special order
Total power(Full Loaded) 15KW 18KW
Container
Max l ength of preform 180mm 180mm
Diameter of preform 15mm-40mm 15mm-40mm
Container Volume 0.1-2.5L 0.1-1.0L
Diameter of neck finish 15mm-45mm 15mm-30mm
Container Diameter 110mm 70mm
Max. Height of container 370mm 250mm
Air system
High pressure Air compressor >1.2m /3.0MPax23 (0.5L)
Dimension & Weight
Blow molding machine 1.9*0.88*1.8M
Oven 1.9*0.66*1.6M
Net Weight 1.3T
