High Speed Aluminum / Copper PCB Punching Machine 0.8mm - 3

High Speed Aluminum / Copper PCB Punching Machine 0.8mm - 3.5 mm Thick

Specification:

Model No.: YSV-1A

Machine Dimension: 960*560*750 mm

Transfer Belt: none

Material of Blade: SHK-9 high speed steel

Cutting Speed: 0-1000 mm / s

Cutting Thickness: 0.8-3.5 mm

Voltage: 220VAC / 110VAC

Weight: 89kg

Feature:

One cutting span is 0-460mm/pcb

cutting blade speed are 2 type: 500mm/s & 300mm/s

operate platform adjusting range from 0 to 50mm

flexible setting design. i.e. micro adjust the upper and lower blade to fit some kinds of thickness of PCB

as per the length of PCB, free setting stop point

Application:

aluminum base board

copper substrate

FR4

glass fiber board

LED light bar panel

pcb circuit board

Maintenance:

take off the power botton and clean the machine after finish working

be careful to protect the upper and lower blade

move the blades and protect them with machine oil

check the screw fastening time to time
